MONOSHOCK - DISASSEMBLED для Ktm 85 SX 17/14 - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    46180348 SHOCK ABSORBER TOP H40 135DEG.
    SHOCK ABSORBER TOP H40 135DEG.
  • 2
    50180213S6 DCC-COMPR.DAMP.CONTROL CPL.
    DCC-COMPR.DAMP.CONTROL CPL.
  • 3
    46180007 ADAPTOR BUSH KGW 12X24
    ADAPTOR BUSH KGW 12X24
  • 4
    46180003 OIL SEAL KGW D=25
    OIL SEAL KGW D=25
  • 5
    50180168 WASHER KGW D=25
    WASHER KGW D=25
  • 6
    50180005 BUSHING KGW 1525 HD
    BUSHING KGW 1525 HD
  • 8
    50180095 BLEED PLUG R 1/8
    BLEED PLUG R 1/8
  • 12
    52000014 STICKER WP 35X55
    STICKER WP 35X55
  • 13
    50180266 RES. SCREW L=113,5 D=52 BLACK
    RES. SCREW L=113,5 D=52 BLACK
  • 14
    46180014 O-RING VITON 41X5
    O-RING VITON 41X5
  • 15
    46180002 SEPARATION PISTON D=52, H=32
    SEPARATION PISTON D=52, H=32
  • 16
    46180015 PISTON RING 3,9X1,5X156
    PISTON RING 3,9X1,5X156
  • 18
    50180344 RESERVOIR CAP D=58
    RESERVOIR CAP D=58
  • 19
    46810893 O-RING NBR 5,28X1,78
    O-RING NBR 5,28X1,78
  • 20
    36120151 SCREW PLUG M5X6
    SCREW PLUG M5X6
  • 21
    46811208 RUBBER CAP "DO NOT OPEN"
    RUBBER CAP "DO NOT OPEN"
  • 25
    46810016 O-RING NBR 48X2
    O-RING NBR 48X2
  • 27
    46180340 SLEEVE D=48
    SLEEVE D=48
  • 29
    46180352 LOCK WASHER M52X1,5
    LOCK WASHER M52X1,5
  • 30
    46180345 TUBE M52X1,5
    TUBE M52X1,5
  • 35
    46180353 SPRING RETAINER M52X1,5
    SPRING RETAINER M52X1,5
  • 36
    0912050253 AH SCREW DIN0912-M 5X25
    AH SCREW DIN0912-M 5X25
  • 40
    91010201 SPRING (59) 215 45 N/MM D=10
    SPRING (59) 215 45 N/MM D=10
  • 40
    91010272 SPRING 215 30 N/MM D=9,00 ORAN
    SPRING 215 30 N/MM D=9,00 ORAN
  • 40
    91010273 SPRING 215 35 N/MM D=9,25 ORAN
    SPRING 215 35 N/MM D=9,25 ORAN
  • 40
    91010274S SPRING 215 40 N/MM D=9,50 ORG
    SPRING 215 40 N/MM D=9,50 ORG
  • 43
    46180349 SPRING WASHER H=15 D=28
    SPRING WASHER H=15 D=28
  • 45
    46180356 PISTON ROD NUT M10X1
    PISTON ROD NUT M10X1
  • 46
    46810035 O-RING VITON 37,82X1,78
    O-RING VITON 37,82X1,78
  • 47
    46811206 PISTON RING 8X46
    PISTON RING 8X46
  • 48
    36120349 SHIM 10X19X0,30
    SHIM 10X19X0,30
  • 48
    50180032 SHIM 15X25X0,25
    SHIM 15X25X0,25
  • 48
    50180395 RING 10X16X1
    RING 10X16X1
  • 49
    14460016 PISTON + PISTON SPRING
    PISTON + PISTON SPRING
  • 50
    36120312 SHIM 10X16X0,30
    SHIM 10X16X0,30
  • 50
    36120334 SHIM 10X21X0,20
    SHIM 10X21X0,20
  • 50
    36120335 SHIM 10X23X0,20
    SHIM 10X23X0,20
  • 50
    36120336 SHIM 10X25X0,20
    SHIM 10X25X0,20
  • 50
    36120337 SHIM 10X27X0,20
    SHIM 10X27X0,20
  • 50
    36120338 SHIM 10X29X0,20
    SHIM 10X29X0,20
  • 50
    36120339 SHIM 10X31X0,20
    SHIM 10X31X0,20
  • 51
    46180339 SEPARATION BUSH 17X12X18
    SEPARATION BUSH 17X12X18
  • 54
    46810492 SHIM 12X28X0,20
    SHIM 12X28X0,20
  • 54
    46810493 SHIM 12X30X0,20
    SHIM 12X30X0,20
  • 54
    46810494 SHIM 12X32X0,20
    SHIM 12X32X0,20
  • 54
    46810495 SHIM 12X34X0,20
    SHIM 12X34X0,20
  • 54
    46810496 SHIM 12X36X0,20
    SHIM 12X36X0,20
  • 54
    46810518 SHIM 12X26X0,15
    SHIM 12X26X0,15
  • 54
    46810519 SHIM 12X28X0,15
    SHIM 12X28X0,15
  • 54
    46810637 BACKPLATE 12X17X0,30
    BACKPLATE 12X17X0,30
  • 56
    46810492 SHIM 12X28X0,20
    SHIM 12X28X0,20
  • 56
    46810493 SHIM 12X30X0,20
    SHIM 12X30X0,20
  • 56
    46810494 SHIM 12X32X0,20
    SHIM 12X32X0,20
  • 56
    46810520 SHIM 12X30X0,15
    SHIM 12X30X0,15
  • 56
    46810521 SHIM 12X32X0,15
    SHIM 12X32X0,15
  • 56
    46810522 SHIM 12X34X0,15
    SHIM 12X34X0,15
  • 56
    46810523 SHIM 12X36X0,15
    SHIM 12X36X0,15
  • 56
    46810524 SHIM 12X38X0,15
    SHIM 12X38X0,15
  • 56
    46810525 SHIM 12X40X0,15
    SHIM 12X40X0,15
  • 56
    46810637 BACKPLATE 12X17X0,30
    BACKPLATE 12X17X0,30
  • 57
    46180179 REBOUND DISC H=0
    REBOUND DISC H=0
  • 57
    46180337 REBOUND DISC H=4
    REBOUND DISC H=4
  • 58
    46180441 PISTON 5X4,5X/6X6
    PISTON 5X4,5X/6X6
  • 60
    46180343 TAP PISTON ROD D=13,5
    TAP PISTON ROD D=13,5
  • 61
    46180342 SPINDEL D=18 LC=159
    SPINDEL D=18 LC=159
  • 62
    50180397 O-RING VITON 5X1,5
    O-RING VITON 5X1,5
  • 64
    46180346 NEEDLE REBOUND L=169
    NEEDLE REBOUND L=169
  • 65
    46180018 O-RING NBR 7,5X2
    O-RING NBR 7,5X2
  • 66
    46180350 NEEDLE GUIDE
    NEEDLE GUIDE
  • 72
    46180341S ADAPTOR CPL. D=46 H=28 D=38
    ADAPTOR CPL. D=46 H=28 D=38
  • 76
    46180355 RESERVOIR CAP M16X1
    RESERVOIR CAP M16X1
  • 77
    46180013 O-RING NBR 12X1
    O-RING NBR 12X1
  • 78
    50180222 O-RING NBR 4X1,5
    O-RING NBR 4X1,5
  • 79
    48600028 SPRING D=2,9 L=7,9
    SPRING D=2,9 L=7,9
  • 80
    40540603 STEEL BALL D=3MM
    STEEL BALL D=3MM
  • 81
    46180006 ADJUSTING SCREW L=15,5
    ADJUSTING SCREW L=15,5
  • 82
    46180016 ADJUSTING ADAPTOR REBOUND
    ADJUSTING ADAPTOR REBOUND
  • 83
    50180410 INTERM.RING D=58
    INTERM.RING D=58
  • 85
    46810010 CIRCLIP 49X1,5
    CIRCLIP 49X1,5
  • 86
    46180338 CAP D=46 H=9,5
    CAP D=46 H=9,5
  • 87
    50180276 BUMP RUBBER WP60 D=18-26
    BUMP RUBBER WP60 D=18-26
  • 88
    50180283 CONTRA NUT M18X1 H=5
    CONTRA NUT M18X1 H=5
  • 90
    46180347 SHOCK ABSORBER BOT. KGW L=54,5
    SHOCK ABSORBER BOT. KGW L=54,5
  • 98
    50180466S1 SHOCK ABSORBER FLUID 5 LT
    SHOCK ABSORBER FLUID 5 LT
