LIGHTING SYSTEM для Ktm 950 SUPERMOTO - 2005 года выпуска`
-
№АртикулНазвание
-
158614001000 HEAD LIGHT RIGHT TR.HEAD LIGHT RIGHT TR.
-
158614001100 HEAD LIGHT LEFT TR.HEAD LIGHT LEFT TR.
-
658614001050 RUBBER CAP FOR HEAD LIGHTRUBBER CAP FOR HEAD LIGHT
-
749011435100 BULB 12V 5W (W2,1X9,5D) PHIL.BULB 12V 5W (W2,1X9,5D) PHIL.
-
857111038000 BULB H4 12V 60/55W (P43T)BULB H4 12V 60/55W (P43T)
-
120016050121 SCREW FOR PLASTIC D=5X12SCREW FOR PLASTIC D=5X12
-
2058414025100 FLASHER CPL.FRONT L/S REAR R/SFLASHER CPL.FRONT L/S REAR R/S
-
2158414026100 FLASHER CPL.FRONT R/S REAR L/SFLASHER CPL.FRONT R/S REAR L/S
-
2244111015100 BULB 12V 10W (BA15S)BULB 12V 10W (BA15S)
-
230125100003 WASHER DIN0125-A10,5WASHER DIN0125-A10,5
-
2458414030000 HH COLLAR NUT M10X1,25 WS=13HH COLLAR NUT M10X1,25 WS=13
-
250797100003 LOCK WASHER DIN6797-J10,5 ZILOCK WASHER DIN6797-J10,5 ZI
-
2658414028100 FLASHER LENS L/S & R/SFLASHER LENS L/S & R/S
-
3058614040044 REAR LIGHT CPL.REAR LIGHT CPL.
-
3158614040050 METAMOLL FOR HEAD LIGHTMETAMOLL FOR HEAD LIGHT
-
3260014048000 BULB 12V 21WBULB 12V 21W
-
330985060003 SELF LOCK. NUT DIN0985-M 6SELF LOCK. NUT DIN0985-M 6
-
340021060003 WASHER DIN9021-A 6,4WASHER DIN9021-A 6,4
-
3558214069051 RUBBER GROMMET 16X10,8X3RUBBER GROMMET 16X10,8X3
-
3962511076000 WIRING HARNESS REARWIRING HARNESS REAR
-
4058414047000 LICENSE-PLATE ILLUMINATIONLICENSE-PLATE ILLUMINATION
-
410021050003 WASHER DIN9021-A 5,3WASHER DIN9021-A 5,3
-
420985050003 SELF LOCKING NUT DIN0985-M 5SELF LOCKING NUT DIN0985-M 5
-
4358614021000 ADJ. SCREW HEAD LIGHTADJ. SCREW HEAD LIGHT
-
440770080020 O-RING 8X2 SILICONEO-RING 8X2 SILICONE
-
4558614024000 CLAMPRING F. HEAD LIGHT ADJ.CLAMPRING F. HEAD LIGHT ADJ.
-
4658614018000 ADJUSTINGNUT F. HEAD L. ADJ.ADJUSTINGNUT F. HEAD L. ADJ.
-
4858614063050 TAB HEAD LIGHT ADJ.TAB HEAD LIGHT ADJ.
-
7658611076100 CABLE HARNESS REAR PARTCABLE HARNESS REAR PART
