ENGINE CASE для Ktm 660 RALLYE - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    5853000054430 ENGINE CASE CPL.W.TRAN.BEAR.
    ENGINE CASE CPL.W.TRAN.BEAR.
  • 3
    58530088000 PLUG VISUAL CHECK TRANSMISSION
    PLUG VISUAL CHECK TRANSMISSION
  • 4
    0770020020 O-RING 20X2 VITON
    O-RING 20X2 VITON
  • 5
    50130027000 DOWEL 19 X15,1X12
    DOWEL 19 X15,1X12
  • 6
    51030026100 DOWEL 17 X 13 X 12
    DOWEL 17 X 13 X 12
  • 7
    58530010000 CRANK SHAFT BUSH
    CRANK SHAFT BUSH
  • 9
    58033097000 NEEDLE BEARING HK 2216
    NEEDLE BEARING HK 2216
  • 10
    58330011000 SHIFT MECHANISM SUPPORT
    SHIFT MECHANISM SUPPORT
  • 11
    49030090000 DOWEL 9,8 X 7 X 10
    DOWEL 9,8 X 7 X 10
  • 15
    56530017000 RETAINING PLATE
    RETAINING PLATE
  • 16
    0991060166 FL.HEAD SCR.DIN7991-M6X16 10.9
    FL.HEAD SCR.DIN7991-M6X16 10.9
  • 18
    58530080000 LOCATING SCREW
    LOCATING SCREW
  • 19
    0603082121 SEAL RING CU DIN7603- 8X12X1
    SEAL RING CU DIN7603- 8X12X1
  • 20
    58530039200 ENGI.CASE GASKET SIL C-4400
    ENGI.CASE GASKET SIL C-4400
  • 21
    0985050103 OVAL HEAD SCR. DIN7985-M 5X10
    OVAL HEAD SCR. DIN7985-M 5X10
  • 22
    0472200010 LOCKRING DIN 472 20X1MM
    LOCKRING DIN 472 20X1MM
  • 23
    0412174012 CYLIND.ROLL.NJ 203 ECP/C3
    CYLIND.ROLL.NJ 203 ECP/C3
  • 24
    0625618050 BALL BEARING 61805 C3
    BALL BEARING 61805 C3
  • 26
    58030010100 HOSE CONNECTOR M20X1,5 SPLICE.
    HOSE CONNECTOR M20X1,5 SPLICE.
  • 27
    58430095100 INSPECT.GLASS GW 20-7 MINERAL
    INSPECT.GLASS GW 20-7 MINERAL
  • 28
    58440091000 STOP DISK 33 X 58 X 1,5
    STOP DISK 33 X 58 X 1,5
  • 29
    5853002600030 CLUTCH COVER OUTS.CPL.BLACK
    CLUTCH COVER OUTS.CPL.BLACK
  • 30
    5853000100030 CLUTCH COVER BLACK
    CLUTCH COVER BLACK
  • 31
    58530025000 CLUTCH COVER GASKET
    CLUTCH COVER GASKET
  • 32
    0770165024 O-RING 165X2,4
    O-RING 165X2,4
  • 33
    58030020100 PLUG CPL. M24X3
    PLUG CPL. M24X3
  • 34
    0770191015 O-RING 19,00X3,00 NBR
    O-RING 19,00X3,00 NBR
  • 35
    60030064090 OIL JET 90 M6X0,75 WS8
    OIL JET 90 M6X0,75 WS8
  • 38
    54403135000 PLASTIC CAP SFL10
    PLASTIC CAP SFL10
  • 39
    44011076305 CABLE TIE 300/4,8MM BLACK
    CABLE TIE 300/4,8MM BLACK
  • 40
    58530060000 SPROCKET COVER
    SPROCKET COVER
  • 41
    54613038150 BUSHING 6,5X8X11
    BUSHING 6,5X8X11
  • 42
    58530047000 CHAIN DAMPERSHEET 16/17T
    CHAIN DAMPERSHEET 16/17T
  • 44
    58030021000 OILDRAIN PLUG W.MAG. M 12X1,5
    OILDRAIN PLUG W.MAG. M 12X1,5
  • 45
    58038017100 CU-SEAL RING DIN7603-22X27X2
    CU-SEAL RING DIN7603-22X27X2
  • 46
    58038019100 OIL DRAIN PLUG M22X1,5
    OIL DRAIN PLUG M22X1,5
  • 47
    58038022000 CU-SEAL RING DIN7603-12X18X1,5
    CU-SEAL RING DIN7603-12X18X1,5
  • 48
    0908120153 PLUG DIN0908-M12X1,5
    PLUG DIN0908-M12X1,5
  • 50
    58538023000 OIL PRES.SPRING 5 BAR RED
    OIL PRES.SPRING 5 BAR RED
  • 51
    58038028000 VALVE PISTON D=10MM
    VALVE PISTON D=10MM
  • 52
    58033090000 NEEDLE BEARING RNA 4903
    NEEDLE BEARING RNA 4903
  • 53
    0760223270 SHAFT SEAL RING 22X32X7 BSL
    SHAFT SEAL RING 22X32X7 BSL
  • 55
    58530399100 GASKET SET
    GASKET SET
  • 60
    0015060253 HH COLLAR SCREW M 6X25 WS=8
    HH COLLAR SCREW M 6X25 WS=8
  • 61
    0015060303 HH COLLAR SCREW M 6X30 WS=8
    HH COLLAR SCREW M 6X30 WS=8
  • 62
    0015060353 HH COLLAR SCREW M 6X35 WS=8
    HH COLLAR SCREW M 6X35 WS=8
  • 63
    0015060403 HH COLLAR SCREW M 6X40 WS=8
    HH COLLAR SCREW M 6X40 WS=8
  • 66
    0015060553 HH COLLAR SCREW M 6X55 WS=8
    HH COLLAR SCREW M 6X55 WS=8
  • 68
    0015060653 HH COLLAR SCREW M 6X65 WS=8
    HH COLLAR SCREW M 6X65 WS=8
