NEW PARTS ENGINE для Ktm 540 SXS - 2005 года выпуска

  • №
    Артикул
    Название
  • 29
    59032000100 ANTIHOPPING CLUTCH
    ANTIHOPPING CLUTCH
  • 30
    59032010100 INTERMEDIATE DISC 1MM
    INTERMEDIATE DISC 1MM
  • 31
    59032010200 INTERMEDIATE DISC 1,4MM
    INTERMEDIATE DISC 1,4MM
  • 32
    59032011100 LINING DISC 2MM
    LINING DISC 2MM
  • 33
    0015050253 HH COLLAR SCREW M 5X25 WS=8
    HH COLLAR SCREW M 5X25 WS=8
  • 34
    59032006100 WASHER 5,5X20X1,5
    WASHER 5,5X20X1,5
  • 35
    59032006200 ADJUST. SHIM 12,5X20X1
    ADJUST. SHIM 12,5X20X1
  • 35
    59032006300 ADJUST. SHIM 12,5X20X2
    ADJUST. SHIM 12,5X20X2
  • 35
    59032006400 ADJUST. SHIM 12,5X20X2,5
    ADJUST. SHIM 12,5X20X2,5
  • 36
    59032005100 CLUTCH SPRING APTC
    CLUTCH SPRING APTC
  • 37
    59032007100 SAFETY SCREW APTC
    SAFETY SCREW APTC
  • 38
    59032003400 PRESSURE CAP APTC
    PRESSURE CAP APTC
  • 39
    54637098200 AXIAL WASHER AS1226 12X26X1
    AXIAL WASHER AS1226 12X26X1
  • 40
    59032002450 OUTER CLUTCH APTC
    OUTER CLUTCH APTC
  • 41
    59032004100 DRIVING SLEEVE APTC
    DRIVING SLEEVE APTC
  • 42
    59032004200 OPENING SPRING APTC
    OPENING SPRING APTC
  • 43
    59032002400 INNER HUB APTC
    INNER HUB APTC
  • 49
    SXS04450244 INNER CLUTCH COVER CPL.
    INNER CLUTCH COVER CPL.
  • 50
    SXS04450036 GASKET FOR OUTER CLUTCH COVER
    GASKET FOR OUTER CLUTCH COVER
  • 51
    SXS04450235 OUTER CLUTCH COVER
    OUTER CLUTCH COVER
  • 52
    0984060163 AH SCREW DIN6912-M 6X16
    AH SCREW DIN6912-M 6X16
  • 55
    SXS03530017 PISTONRING SET
    PISTONRING SET
  • 76
    0912060551 AH SCREW DIN0912-M 6X55 12.9
    AH SCREW DIN0912-M 6X55 12.9
  • 77
    0912101503 AH SCREW DIN 912 M10X150 10.9
    AH SCREW DIN 912 M10X150 10.9
  • 78
    0015060553 HH COLLAR SCREW M 6X55 WS=8
    HH COLLAR SCREW M 6X55 WS=8
  • 79
    SXS04530006 ENGINE CASE CPL.
    ENGINE CASE CPL.
  • 80
    51030026100 DOWEL 17 X 13 X 12
    DOWEL 17 X 13 X 12
  • 81
    59030024000 DOWEL 17 X 19 X 12
    DOWEL 17 X 19 X 12
  • 82
    58038022000 CU-SEAL RING DIN7603-12X18X1,5
    CU-SEAL RING DIN7603-12X18X1,5
  • 83
    58030021000 OILDRAIN PLUG W.MAG. M 12X1,5
    OILDRAIN PLUG W.MAG. M 12X1,5
  • 84
    SXS04530016 PISTON CPL. D=100MM
    PISTON CPL. D=100MM
  • 85
    SXS03530020 CRANKSHAFT STROKE=68 L=121
    CRANKSHAFT STROKE=68 L=121
  • 86
    SXS03530021 CON. ROD REP. SET
    CON. ROD REP. SET
  • 87
    SXS03530014 CYLINDER HEAD GASKET D=100
    CYLINDER HEAD GASKET D=100
  • 88
    SXS03530010 CYLINDER D=100MM, L=76MM
    CYLINDER D=100MM, L=76MM
  • 89
    SXS04530014 HOSE CONNECTOR M20X1,5
    HOSE CONNECTOR M20X1,5
  • 90
    SXS03530012 CYLINDER BASE GASKET
    CYLINDER BASE GASKET
  • 91
    59838035000 OIL PIPE
    OIL PIPE
  • 92
    59836013000 TIMING CHAIN 94 ROLLS
    TIMING CHAIN 94 ROLLS
  • 93
    59036010100 CAMSHAFT 8/06
    CAMSHAFT 8/06
  • 97
    60029015000 PISTON RING COMPRESSOR CPL.
    PISTON RING COMPRESSOR CPL.
