FORK LEGS для Ktm 540 SXS - 2005 года выпуска

  • №
    Артикул
    Название
  • 2
    46810340 O-RING NBR 45X2
    O-RING NBR 45X2
  • 3
    48600018 KNOB REBOUNG ADJUSTER
    KNOB REBOUNG ADJUSTER
  • 5
    40540603 STEEL BALL D=3MM
    STEEL BALL D=3MM
  • 6
    48600028 SPRING D=2,9 L=7,9
    SPRING D=2,9 L=7,9
  • 7
    48600044 O-RING NBR 6X1,5
    O-RING NBR 6X1,5
  • 10
    48600043 O-RING NBR 12X1,5
    O-RING NBR 12X1,5
  • 11
    48600019 HOLDER F.ADJUSTMENT TUBE D=4MM
    HOLDER F.ADJUSTMENT TUBE D=4MM
  • 12
    48600381 OUTER TUBE L=577MM D=54/60MM
    OUTER TUBE L=577MM D=54/60MM
  • 13
    48600016 GUIDING RING D=58MM
    GUIDING RING D=58MM
  • 15
    48600205 DU-BUSH 48X52X12
    DU-BUSH 48X52X12
  • 16
    48600013 SUPPORT RING 50 X 57,6 X 1,5
    SUPPORT RING 50 X 57,6 X 1,5
  • 17
    48600399 OIL SEAL RING 48X57,8X9,5
    OIL SEAL RING 48X57,8X9,5
  • 18
    48600070 LOCK WASHER SB58
    LOCK WASHER SB58
  • 19
    48600400 DUST STRIPPER D=48 58,4X11,8
    DUST STRIPPER D=48 58,4X11,8
  • 22
    48600204 DU-BUS 47X49X20
    DU-BUS 47X49X20
  • 23
    48600377 INNER TUBE D=48 L=595
    INNER TUBE D=48 L=595
  • 24
    48600380S HYDR.STOP L=200MM D=31,9 CPL.
    HYDR.STOP L=200MM D=31,9 CPL.
  • 30
    48600092 ADJUSTMENT TUBE L=517MM
    ADJUSTMENT TUBE L=517MM
  • 31
    48600409 PISTON ROD D=14 L=551 M11X1
    PISTON ROD D=14 L=551 M11X1
  • 33
    48600189 NEEDLE REBOUND
    NEEDLE REBOUND
  • 34
    48600046 O-RING NBR 3X1,5
    O-RING NBR 3X1,5
  • 35
    48600033 SPRING REBOUND NEEDLE C=4N/MM
    SPRING REBOUND NEEDLE C=4N/MM
  • 36
    48600113 WASHER 32X42X2,5
    WASHER 32X42X2,5
  • 37
    48600036 SPACER 42X26,5X2,5
    SPACER 42X26,5X2,5
  • 37
    48600037 SPACER 42X26,5X5
    SPACER 42X26,5X5
  • 37
    48600053 SPACER 42X26,5X1,5
    SPACER 42X26,5X1,5
  • 38
    91410011S SPRING 3,6N/MM SET
    SPRING 3,6N/MM SET
  • 38
    91410012S SPRING 3,8N/MM SET D=4,9MM
    SPRING 3,8N/MM SET D=4,9MM
  • 38
    91410013S SPRING 4ON/MM SET D=5,0MM
    SPRING 4ON/MM SET D=5,0MM
  • 38
    91410014S SPRING 4,2N/MM SET D=5,OMM
    SPRING 4,2N/MM SET D=5,OMM
