CARBURETOR KEIHIN PWK для Ktm 250 SXS - 2005 года выпуска`
-
№АртикулНазвание
-
154831001244 CARBURETOR PWK38-S AGCARBURETOR PWK38-S AG
-
754531607038 IDLE JET 38 KEIHINIDLE JET 38 KEIHIN
-
754531607040 IDLE JET 40 KEIHINIDLE JET 40 KEIHIN
-
754531607042 IDLE JET 42 KEININIDLE JET 42 KEININ
-
754531607045 IDLE JET 45 KEIHINIDLE JET 45 KEIHIN
-
754531607048 IDLE JET 48 KEIHINIDLE JET 48 KEIHIN
-
754531607050 IDLE JET 50 KEIHINIDLE JET 50 KEIHIN
-
857331008000 ARM PIN FLOATARM PIN FLOAT
-
957331009000 FLOAT CPL.FLOAT CPL.
-
1054831010000 GASKET FLOAT CHAMBERGASKET FLOAT CHAMBER
-
1154831011000 FLOAT CHAMBER PWK38-SAGFLOAT CHAMBER PWK38-SAG
-
1254531612100 RETAINING PLATE FOR BLEEDERRETAINING PLATE FOR BLEEDER
-
140016040163 HH COLLAR SCREW M 4X16 WS=6HH COLLAR SCREW M 4X16 WS=6
-
1554531615000 SPRING FOR ADJUSTMENT SCREWSPRING FOR ADJUSTMENT SCREW
-
1754531617000 ADJUSTMENT SCREWADJUSTMENT SCREW
-
1854631118000 SPRINGSPRING
-
1954631219100 ADJUSTMENT SCREW M 5ADJUSTMENT SCREW M 5
-
2054631020000 FLOAT VALVE CPL. PWK 38 AG PIFLOAT VALVE CPL. PWK 38 AG PI
-
2154531621000 CLAMPCLAMP
-
2354531623155 MAIN JET 155 KEIHINMAIN JET 155 KEIHIN
-
2354531623158 MAIN JET 158 KEIHINMAIN JET 158 KEIHIN
-
2354531623162 MAIN JET 162 KEIHINMAIN JET 162 KEIHIN
-
2354531623165 MAIN JET 165 KEIHINMAIN JET 165 KEIHIN
-
2354531623168 MAIN JET 168 KEIHINMAIN JET 168 KEIHIN
-
2354531623170 MAIN JET 170 KEIHINMAIN JET 170 KEIHIN
-
2354531623172 MAIN JET 172 KEIHINMAIN JET 172 KEIHIN
-
2354531623175 MAIN JET 175 KEIHINMAIN JET 175 KEIHIN
-
2354531623178 MAIN JET 178 KEIHINMAIN JET 178 KEIHIN
-
2554831025000 SPECIAL-AN-SCREW M 4X12SPECIAL-AN-SCREW M 4X12
-
2654831029000 THROTTLE CABLE HOLDER M6X0,75THROTTLE CABLE HOLDER M6X0,75
-
2754831027000 CARBURETOR COVER PWK38-SAGCARBURETOR COVER PWK38-SAG
-
2854831028000 GASKET FOR CARBURETOR COVERGASKET FOR CARBURETOR COVER
-
2954531629000 CLIP FOR JET NEEDLECLIP FOR JET NEEDLE
-
3054831030000 SLIDING SPRINGSLIDING SPRING
-
3154631231000 SPRING CAPSPRING CAP
-
3254631232000 NIPPLENIPPLE
-
3454531636004 JET NEEDLE NOZ D KEIHINJET NEEDLE NOZ D KEIHIN
-
3454531636005 JET NEEDLE NOZ E KEIHINJET NEEDLE NOZ E KEIHIN
-
3454531636006 JET NEEDLE NOZ F KEIHINJET NEEDLE NOZ F KEIHIN
-
3454531636007 JET NEEDLE NOZ G KEIHINJET NEEDLE NOZ G KEIHIN
-
3454531636008 JET NEEDLE NOZ H KEIHINJET NEEDLE NOZ H KEIHIN
-
3454731034600 JET NEEDLE KEIHIN N3CJJET NEEDLE KEIHIN N3CJ
-
3454731134000 JET NEEDLE KEIHIN N3EGJET NEEDLE KEIHIN N3EG
-
3454731034700 JET NEEDLE KEIHIN N3EHJET NEEDLE KEIHIN N3EH
-
3454731034900 JET NEEDLE KEIHIN N3EWJET NEEDLE KEIHIN N3EW
-
3554631035000 THROTTLE VALVE 7 FOR 38 PJTHROTTLE VALVE 7 FOR 38 PJ
-
4554631245000 STARTER PISTON CPL.STARTER PISTON CPL.
-
4654531696000 CLAMP 6 MMCLAMP 6 MM
-
4731007007101 PVC-HOSE 4X6MMPVC-HOSE 4X6MM
-
4852031137001 PVC-HOSE 3X5MMPVC-HOSE 3X5MM
-
4957331014000 HOLDING BOLTHOLDING BOLT
-
500770180230 O-RING 18,00X2,30 NBR 70O-RING 18,00X2,30 NBR 70
-
5250331029038 SLIDE STOP L=3SMMSLIDE STOP L=3SMM
-
530770060018 O-RING 6,OOX1,78O-RING 6,OOX1,78
-
7154831071000 WASHER ADJUSTING SCREWWASHER ADJUSTING SCREW
-
7254831072000 O-RING ADJUSTING SCREWO-RING ADJUSTING SCREW
