CYLINDER W/ CYLINDER HEAD для Ktm 250 SXS - 2005 года выпуска

  • №
    Артикул
    Название
  • 5
    54830005144 CYLINDER CPL. W FLANGE
    CYLINDER CPL. W FLANGE
  • 6
    54830006100 CYLINDER HEAD "2508"
    CYLINDER HEAD "2508"
  • 7
    5473700700098 CONTROL COVER R/S
    CONTROL COVER R/S
  • 8
    54737008000 GASKET FOR CONTROL COVER R/S
    GASKET FOR CONTROL COVER R/S
  • 15
    5473700500098 CONTROL COVER US
    CONTROL COVER US
  • 16
    54737006000 GASKET FOR CONTROL COVER US
    GASKET FOR CONTROL COVER US
  • 17
    54830079000 COLLAR SCREW M 8X35 WS=13
    COLLAR SCREW M 8X35 WS=13
  • 18
    56530080000 CU-SEAL RING 8X 16 X I
    CU-SEAL RING 8X 16 X I
  • 20
    0770760021 O-RING 76,00X2,00 V/TON
    O-RING 76,00X2,00 V/TON
  • 21
    0770114020 O-RING 114,00X2,00 SILICONE
    O-RING 114,00X2,00 SILICONE
  • 22
    58336020090 VACUUM CONNECTION M 6X1
    VACUUM CONNECTION M 6X1
  • 23
    31007107001 PVC-HOSE 6X9 MM PER METRE
    PVC-HOSE 6X9 MM PER METRE
  • 24
    50303089000 ANGEL PIECE
    ANGEL PIECE
  • 25
    0835100351 STUD DIN0835-M10X35
    STUD DIN0835-M10X35
  • 26
    0835100403 STUD DIN0835-M10X40
    STUD DIN0835-M10X40
  • 27
    54630044000 COLLAR NUT M10 WS=13
    COLLAR NUT M10 WS=13
  • 30
    54830030002 GASKET CYLINDER BASE 0,2MM
    GASKET CYLINDER BASE 0,2MM
  • 30
    54830030004 GASKET CYLINDER BASE 0,4MM
    GASKET CYLINDER BASE 0,4MM
  • 30
    54830030005 GASKET CYLINDER BASE 0,5MM
    GASKET CYLINDER BASE 0,5MM
  • 30
    54830030075 GASKET CYLINDER BASE 0,75MM
    GASKET CYLINDER BASE 0,75MM
  • 36
    0770116241 O-RING 11,3 X2,4 SILICON
    O-RING 11,3 X2,4 SILICON
  • 37
    0770440030 O-RING 44,00X3,00 VITON
    O-RING 44,00X3,00 VITON
  • 38
    51005074000 RETAINING PLATE
    RETAINING PLATE
  • 47
    0912060303 AH SCREW DIN0912-M 6X30
    AH SCREW DIN0912-M 6X30
  • 50
    0014050123 HH COLLAR SCREW M 5X12 WS=6
    HH COLLAR SCREW M 5X12 WS=6
