BRAKE CALIPER FRONT для Ktm 525 SMR - 2004 года выпуска
-
№АртикулНазвание
-
159413015044 BR.CALIPER FR. CPL. 6-PIST.BR.CALIPER FR. CPL. 6-PIST.
-
1159413011000 BRAKE HOSE FR. SMR L=1130MMBRAKE HOSE FR. SMR L=1130MM
-
1980013019000 REPAIR KIT CPL. 6-PISTONSREPAIR KIT CPL. 6-PISTONS
-
2550213025000 HOLLOW SCREW M10X1X19HOLLOW SCREW M10X1X19
-
2642013226000 CU-SEAL RING DIN7603-10X16X1CU-SEAL RING DIN7603-10X16X1
-
3080013030000 BRAKE PAD SET FR. SINTER 11005BRAKE PAD SET FR. SINTER 11005
-
3080013030100 BRAKE PAD SET FR.SINTER 110082BRAKE PAD SET FR.SINTER 110082
-
320125080003 WASHER DIN0125-A 8,4WASHER DIN0125-A 8,4
-
3336003014000 LOCK WASHER 8MMLOCK WASHER 8MM
-
350015080353 HH COLLAR SCREW M 8X35 WS=10HH COLLAR SCREW M 8X35 WS=10
-
606899785 LOCTITE 243 BLUE 6CCMLOCTITE 243 BLUE 6CCM
