FRONT FORK для Ktm 50 SX Mini Adventure - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    45101000044 FORK CPL.
    FORK CPL.
  • 5
    7501476A TOP FORK PLATE
    TOP FORK PLATE
  • 6
    0912080303 AH SCREW DIN0912-M 8X30
    AH SCREW DIN0912-M 8X30
  • 8
    7504212AC SCREW CAP
    SCREW CAP
  • 9
    7528010 O-RING
    O-RING
  • 11
    7518031 PRE LOAD BUSH L=55MM
    PRE LOAD BUSH L=55MM
  • 12
    75141169 SPRING
    SPRING
  • 13
    7533297 DUST SEAL
    DUST SEAL
  • 14
    7523264 STOP RING
    STOP RING
  • 15
    7528230 OIL SEAL 32/42/6,5-9,5
    OIL SEAL 32/42/6,5-9,5
  • 16
    7522166AA WASHER D42X32,5X1,5
    WASHER D42X32,5X1,5
  • 17
    7524157 PISTON RING D32 (ONLY FOR REBOUND DAMPING)
    PISTON RING D32 (ONLY FOR REBOUND DAMPING)
  • 18
    78031105 PISTON ROD REBOUND MINI 02 (REBOUND DAMPING - LEFT SIDE)
    PISTON ROD REBOUND MINI 02 (REBOUND DAMPING - LEFT SIDE)
  • 18
    78031104 PISTON ROD COMPRESSION MINI 02 (COMPRESSION DAMP- RIGHT SIDE)
    PISTON ROD COMPRESSION MINI 02 (COMPRESSION DAMP- RIGHT SIDE)
  • 19
    75141015 REBOUND SPRING
    REBOUND SPRING
  • 20
    75031538A/A SLIDER LEFT SIDE
    SLIDER LEFT SIDE
  • 21
    75031538A/A/R SLIDER LEFT SIDE CPL.
    SLIDER LEFT SIDE CPL.
  • 22
    7522225 WASHER 14X8X1,5
    WASHER 14X8X1,5
  • 25
    77051124 BOT. FORK PLATE CPL.
    BOT. FORK PLATE CPL.
  • 26
    7708247/R FORK TUBE R/S
    FORK TUBE R/S
  • 27
    7708248/R FORK TUBE L/S
    FORK TUBE L/S
  • 28
    7512068 FOOT BUFFER
    FOOT BUFFER
  • 29
    75031366A/A SLIDER RIGHT SIDE
    SLIDER RIGHT SIDE
  • 31
    75031366A/K/R SLIDER CPL. RIGHT SIDE
    SLIDER CPL. RIGHT SIDE
  • 34
    50301036000 STEER.HEAD SCREW M20X1,5 WS=27
    STEER.HEAD SCREW M20X1,5 WS=27
  • 35
    45101081000 STEER.STEM B. CPL.
    STEER.STEM B. CPL.
  • 36
    0015080303 HH COLLAR SCREW M8X30 WS=10
    HH COLLAR SCREW M8X30 WS=10
  • 37
    0912100250 AH SCREW DIN0912-M10X25 W.LOCK
    AH SCREW DIN0912-M10X25 W.LOCK
  • 38
    50301038000 HANDLEBAR CLAMP D=22MM
    HANDLEBAR CLAMP D=22MM
  • 39
    45101039000 HANDLEBAR SUPPORT D=22MM
    HANDLEBAR SUPPORT D=22MM
  • 41
    0985050003 SELF LOCKING NUT DIN0985-M 5
    SELF LOCKING NUT DIN0985-M 5
  • 42
    45001070000 BRAKE CABLE GUIDE
    BRAKE CABLE GUIDE
  • 43
    0015050163 HH COLLAR SCREW M 5X16 WS=8
    HH COLLAR SCREW M 5X16 WS=8
  • 44
    7547325 STICKER LEFT SIDE MARZOCCHI
    STICKER LEFT SIDE MARZOCCHI
  • 44
    7547331 STICKER RIGHT SIDE MARZOCCHI
    STICKER RIGHT SIDE MARZOCCHI
