COWLING для Kawasaki NINJA H2R (ZX1000PFF) - 2015 года выпуска
-
№АртикулНазвание
-
1105611056-7098 BRACKET, INNER COVERBRACKET, INNER COVER
-
1409314093-0315 COVER, INNER, LEFT HANDCOVER, INNER, LEFT HAND
-
14093A14093-0316 COVER, INNER, RIGHT HANDCOVER, INNER, RIGHT HAND
-
3506335063-0990-46R STAY, METER, M.F.S.BLACKSTAY, METER, M.F.S.BLACK
-
3915439154-0350 WINDSHIELDWINDSHIELD
-
3915639156-1900 PAD, 20X30X24PAD, 20X30X24
-
39156A39156-1903 PAD, 30X30X15PAD, 30X30X15
-
5505655056-5299-53F COWLING-ASSY, UPPER, R.CARBONCOWLING-ASSY, UPPER, R.CARBON
-
5943759437-0015 STABILIZER, WING, LEFT HAND, CFRPSTABILIZER, WING, LEFT HAND, CFRP
-
59437A59437-0016 STABILIZER, WING, RIGHT HAND, CFRPSTABILIZER, WING, RIGHT HAND, CFRP
-
9203992039-0060 RIVETRIVET
-
9215492154-1292 BOLT, SOCKET, 5X10BOLT, SOCKET, 5X10
-
92154A92154-1561 BOLT, SOCKET, 5X12BOLT, SOCKET, 5X12
-
92154B92154-1647 BOLT, SOCKET, 4X15BOLT, SOCKET, 4X15
-
92154C92154-1710 BOLT, SOCKET, 8X52BOLT, SOCKET, 8X52
-
92154D92154-1728 BOLT, SOCKET, 6X22BOLT, SOCKET, 6X22
-
9220092200-1388 WASHER, 6.5X14X1WASHER, 6.5X14X1
-
92200A92200-1699 WASHER, 4.1X7.4X0.5WASHER, 4.1X7.4X0.5
-
92200B92200-1730 WASHER, 5.2X10X0.5WASHER, 5.2X10X0.5
-
9221092210-0067 NUT, 4MMNUT, 4MM
-
92210A92210-1132 NUT, CAP, 8MMNUT, CAP, 8MM
