COWLING для Kawasaki NINJA H2R (ZX1000PFF) - 2015 года выпуска

  • №
    Артикул
    Название
  • 11056
    11056-7098 BRACKET, INNER COVER
    BRACKET, INNER COVER
  • 14093
    14093-0315 COVER, INNER, LEFT HAND
    COVER, INNER, LEFT HAND
  • 14093A
    14093-0316 COVER, INNER, RIGHT HAND
    COVER, INNER, RIGHT HAND
  • 35063
    35063-0990-46R STAY, METER, M.F.S.BLACK
    STAY, METER, M.F.S.BLACK
  • 39154
    39154-0350 WINDSHIELD
    WINDSHIELD
  • 39156
    39156-1900 PAD, 20X30X24
    PAD, 20X30X24
  • 39156A
    39156-1903 PAD, 30X30X15
    PAD, 30X30X15
  • 55056
    55056-5299-53F COWLING-ASSY, UPPER, R.CARBON
    COWLING-ASSY, UPPER, R.CARBON
  • 59437
    59437-0015 STABILIZER, WING, LEFT HAND, CFRP
    STABILIZER, WING, LEFT HAND, CFRP
  • 59437A
    59437-0016 STABILIZER, WING, RIGHT HAND, CFRP
    STABILIZER, WING, RIGHT HAND, CFRP
  • 92039
    92039-0060 RIVET
    RIVET
  • 92154
    92154-1292 BOLT, SOCKET, 5X10
    BOLT, SOCKET, 5X10
  • 92154A
    92154-1561 BOLT, SOCKET, 5X12
    BOLT, SOCKET, 5X12
  • 92154B
    92154-1647 BOLT, SOCKET, 4X15
    BOLT, SOCKET, 4X15
  • 92154C
    92154-1710 BOLT, SOCKET, 8X52
    BOLT, SOCKET, 8X52
  • 92154D
    92154-1728 BOLT, SOCKET, 6X22
    BOLT, SOCKET, 6X22
  • 92200
    92200-1388 WASHER, 6.5X14X1
    WASHER, 6.5X14X1
  • 92200A
    92200-1699 WASHER, 4.1X7.4X0.5
    WASHER, 4.1X7.4X0.5
  • 92200B
    92200-1730 WASHER, 5.2X10X0.5
    WASHER, 5.2X10X0.5
  • 92210
    92210-0067 NUT, 4MM
    NUT, 4MM
  • 92210A
    92210-1132 NUT, CAP, 8MM
    NUT, CAP, 8MM
