SUSPENSION - SHOCK ABSORBER для Kawasaki ER-6N (ER650C9F) - 2009 года выпуска

  • №
    Артикул
    Название
  • 411
    411AA1200 WASHER-PLAIN, 12MM
    WASHER-PLAIN, 12MM
  • 670
    670B2012 O-RING, 12MM (JKAER650CCDA13243 AND ABOVE)
    O-RING, 12MM (JKAER650CCDA13243 AND ABOVE)
  • 42036
    42036-0024 SLEEVE, 12.1X18X32
    SLEEVE, 12.1X18X32
  • 45014
    45014-0223-458 SHOCKABSORBER (P.SILVER)
    SHOCKABSORBER (P.SILVER)
  • 92046
    92046-1272 BEARING-NEEDLE, SFYZM182417
    BEARING-NEEDLE, SFYZM182417
  • 92049
    92049-0133 SEAL-OIL
    SEAL-OIL
  • 92055
    92055-1563 O-RING, ID=11.4 (UP TO JKAER650CCDA13242)
    O-RING, ID=11.4 (UP TO JKAER650CCDA13242)
  • 92152
    92152-0662 COLLAR, 12.1X16.8X2.1 (UP TO JKAER650CCDA13242)
    COLLAR, 12.1X16.8X2.1 (UP TO JKAER650CCDA13242)
  • 92152A
    92152-0811 COLLAR, 12.1X16.8X4.4 (JKAER650CCDA13243 AND ABOVE)
    COLLAR, 12.1X16.8X4.4 (JKAER650CCDA13243 AND ABOVE)
  • 92153
    92153-1766 BOLT, FLANGED, 12X55
    BOLT, FLANGED, 12X55
  • 92153A
    92153-1985 BOLT, SOCKET, 12X70
    BOLT, SOCKET, 12X70
  • 92160
    92160-1161 DAMPER, SHOCKABSORBER
    DAMPER, SHOCKABSORBER
  • 92200
    92200-0432 WASHER, 12.5X24X1.6 (UP TO JKAER650CCDA13242)
    WASHER, 12.5X24X1.6 (UP TO JKAER650CCDA13242)
  • 92200A
    92200-0484 WASHER
    WASHER
  • 92200B
    92200-0519 WASHER, 12.5X24X3.2 (JKAER650CCDA13243 AND ABOVE)
    WASHER, 12.5X24X3.2 (JKAER650CCDA13243 AND ABOVE)
  • 92210
    92210-0300 NUT, LOCK, 12MM
    NUT, LOCK, 12MM
