WHEEL - REAR W/ CHAIN для Kawasaki Vulcan 2000 - 2005 года выпуска

  • №
    Артикул
    Название
  • 481
    481J5500 CIRCLIP
    CIRCLIP
  • 550
    550D4035 PIN-COTTER, 4.0X35
    PIN-COTTER, 4.0X35
  • 601A
    601B6006UU BEARING-BALL
    BEARING-BALL
  • 601B
    601B6304UU BEARING-BALL, #6304UUC3
    BEARING-BALL, #6304UUC3
  • 16126
    16126-1365 VALVE
    VALVE
  • 41068
    41068-0007 AXLE, REAR
    AXLE, REAR
  • 41073
    41073-0005 WHEEL-ASSY, REAR
    WHEEL-ASSY, REAR
  • 42033A
    42033-0017 COUPLING-ASSY, REAR HUB
    COUPLING-ASSY, REAR HUB
  • 42036
    42036-1366 SLEEVE, REAR HUB COUPLING, L=22
    SLEEVE, REAR HUB COUPLING, L=22
  • 42046
    42046-003 WASHER, 21X33X2.6
    WASHER, 21X33X2.6
  • 43058
    43058-0004 RING, REAR PULLEY
    RING, REAR PULLEY
  • 49079
    49079-0004-458 PULLEY-BELT, P.SILVER
    PULLEY-BELT, P.SILVER
  • 59011
    59011-0004 BELT, DRIVE (133 TEETH)
    BELT, DRIVE (133 TEETH)
  • 92004A
    92004-0016 STUD, 10X35
    STUD, 10X35
  • 92015
    92015-1335 NUT, FLANGED, 10MM
    NUT, FLANGED, 10MM
  • 92022
    92022-1820 WASHER, 10.5X19X3.2
    WASHER, 10.5X19X3.2
  • 92027
    92027-1902 COLLAR, REAR AXLE, L=21.5
    COLLAR, REAR AXLE, L=21.5
  • 92033
    92033-1043 RING-SNAP, 52MM
    RING-SNAP, 52MM
  • 92049
    92049-1061 SEAL-OIL, 28X52X5
    SEAL-OIL, 28X52X5
  • 92049A
    92049-1263 SEAL-OIL, PJN40556
    SEAL-OIL, PJN40556
  • 92152
    92152-0050 COLLAR, REAR AXLE, L=41 (LEFT)
    COLLAR, REAR AXLE, L=41 (LEFT)
  • 92152A
    92152-0051 COLLAR, REAR HUB, L=210
    COLLAR, REAR HUB, L=210
  • 92153
    92153-0827 BOLT, SOCKET, 6X12
    BOLT, SOCKET, 6X12
  • 92161
    92161-0043 DAMPER, SHOCK, REAR HUB
    DAMPER, SHOCK, REAR HUB
  • 92210
    92210-1134 NUT, CASTLE, 18MM
    NUT, CASTLE, 18MM
