ENGINE MOUNT для Kawasaki KX250F (KX252AKF) - 2019 года выпуска
-
№АртикулНазвание
-
3219032190-0714 BRACKET-ENGINE, FRONTBRACKET-ENGINE, FRONT
-
32190A32190-0715 BRACKET-ENGINE, UPPER, LEFT HANDBRACKET-ENGINE, UPPER, LEFT HAND
-
32190B32190-0717 BRACKET-ENGINE, UPPER, RIGHT HANDBRACKET-ENGINE, UPPER, RIGHT HAND
-
9201592015-1432 NUT, 8MMNUT, 8MM
-
9215392153-0802 BOLT, FLANGED, 10X35BOLT, FLANGED, 10X35
-
9215492154-0380 BOLT, FLANGED, 8X14BOLT, FLANGED, 8X14
-
92154A92154-0517 BOLT, FLANGED, 10X130BOLT, FLANGED, 10X130
-
92154B92154-2102 BOLT, SOCKET, 10X35BOLT, SOCKET, 10X35
-
92154C92154-2155 BOLT, FLANGED, 8X102BOLT, FLANGED, 8X102
-
92154D92154-2156 BOLT, FLANGED, 10X104BOLT, FLANGED, 10X104
-
9221092210-1080 NUT, LOCK, FLANGED, 10MMNUT, LOCK, FLANGED, 10MM
-
92210A92210-1184 NUT, LOCK, 10MMNUT, LOCK, 10MM
