FRONT HUB для Kawasaki SUPER SHERPA CANADA ONLY (KL250G9F) - 2009 года выпуска
-
№АртикулНазвание
-
481481J3500 CIRCLIP-TYPE-C,35MMCIRCLIP-TYPE-C,35MM
-
601601B6202UG BEARING-BALL,#6202UGBEARING-BALL,#6202UG
-
4103441034-0007 DRUM-ASSY, FRONT BRAKEDRUM-ASSY, FRONT BRAKE
-
4106841068-0062 AXLE, FRONTAXLE, FRONT
-
9201592015-1407 NUT,14MMNUT,14MM
-
9214392143-1033 COLLAR,15.2X22X67COLLAR,15.2X22X67
-
92143A92143-1918 COLLAR, FRONT AXLE,L=19.5COLLAR, FRONT AXLE,L=19.5
