FOOTRESTS для Kawasaki KLX250SF (KLX250W9F) - 2009 года выпуска

  • №
    Артикул
    Название
  • 130
    130CA1020 BOLT-FLANGED,10X20
    BOLT-FLANGED,10X20
  • 550
    550AA2515 PIN-COTTER,2.5X15
    PIN-COTTER,2.5X15
  • 34003
    34003-0084-18R HOLDER-STEP, RIGHT HAND,F.S.BLACK
    HOLDER-STEP, RIGHT HAND,F.S.BLACK
  • 34028
    34028-0110 STEP, REAR, LEFT HAND
    STEP, REAR, LEFT HAND
  • 34028A
    34028-0111 STEP, REAR, RIGHT HAND
    STEP, REAR, RIGHT HAND
  • 34028B
    34028-1370 STEP, FRONT, LEFT HAND
    STEP, FRONT, LEFT HAND
  • 34028C
    34028-1371 STEP, FRONT, RIGHT HAND
    STEP, FRONT, RIGHT HAND
  • 92027
    92027-162 COLLAR,6.8X10X12
    COLLAR,6.8X10X12
  • 92043
    92043-115 PIN,8X35.5
    PIN,8X35.5
  • 92144
    92144-1685 SPRING,STEP RETURN, RIGHT HAND
    SPRING,STEP RETURN, RIGHT HAND
  • 92144A
    92144-1749 SPRING,STEP RETURN, LEFT HAND
    SPRING,STEP RETURN, LEFT HAND
  • 92150
    92150-1339 BOLT,FLANGED,6X20
    BOLT,FLANGED,6X20
  • 92150A
    92150-1584 BOLT,SOCKET,8X34
    BOLT,SOCKET,8X34
  • 92160
    92160-1401 DAMPER,STEP
    DAMPER,STEP
  • 92200
    92200-0089 WASHER,8.5X16X1.2
    WASHER,8.5X16X1.2
  • 92200A
    92200-1042 WASHER,10.5X19X2.3
    WASHER,10.5X19X2.3
  • 92200B
    92200-1133 WASHER,SPRING
    WASHER,SPRING
  • 92210
    92210-1080 NUT,LOCK,FLANGED,10MM
    NUT,LOCK,FLANGED,10MM
