CRANKSHAFT - PISTON(S) для Kawasaki KX 250 - 2001 года выпуска

  • №
    Артикул
    Название
  • 13001
    13001-1582 PISTON, ENGINE
    PISTON, ENGINE
  • 13002
    13002-1098 PIN, PISTON
    PIN, PISTON
  • 13008
    13008-1173 RING, SET, PISTON
    RING, SET, PISTON
  • 13031
    13031-1482 CRANKSHAFT, COMP
    CRANKSHAFT, COMP
  • 13032
    13032-1263 ROD, CONNECTING
    ROD, CONNECTING
  • 13033
    13033-1010 BEARING, NEEDLE, KBK18X22X23.8X
    BEARING, NEEDLE, KBK18X22X23.8X
  • 13034
    13034-1108 BEARING, BIG END, B4
    BEARING, BIG END, B4
  • 13035
    13035-1089 PIN, CRANK
    PIN, CRANK
  • 13037
    13037-1611 CRANKSHAFT (LEFT)
    CRANKSHAFT (LEFT)
  • 13037A
    13037-1613 CRANKSHAFT (RIGHT)
    CRANKSHAFT (RIGHT)
  • 13097
    13097-1402 GEAR, PRIMARY SPUR (20 TEETH)
    GEAR, PRIMARY SPUR (20 TEETH)
  • 59051
    59051-1248 GEAR, SPUR (27 TEETH)
    GEAR, SPUR (27 TEETH)
  • 92026
    92026-1547 SPACER
    SPACER
  • 92033
    92033-025 RING, SNAP, 20X25.5X1.2
    RING, SNAP, 20X25.5X1.2
  • 92033A
    92033-1267 RING, SNAP, PISTON PIN
    RING, SNAP, PISTON PIN
