GEAR CHANGE DRUM/SHIFT FORK(S) для Kawasaki Prairie 400 4x4 (KVF400-C4) - 2002 года выпуска
-
№АртикулНазвание
-
1310713107-1413 SHAFT, IDLERSHAFT, IDLER
-
1313913139-1084 SHIFTER, FORWARD HI & REVERSESHIFTER, FORWARD HI & REVERSE
-
13139A13139-1088 SHIFTER, FORWARD LOWSHIFTER, FORWARD LOW
-
1326013260-1734 GEAR, FORWARD LOW (49 TEETH)GEAR, FORWARD LOW (49 TEETH)
-
13260A13260-1735 GEAR, IDLE SHAFT (36 TEETH)GEAR, IDLE SHAFT (36 TEETH)
-
13260B13260-1737 GEAR, FORWARD HIGH (42 TEETH)GEAR, FORWARD HIGH (42 TEETH)
-
3913539135-1058 SPROCKET-DRIVEN, REVERSE (42 TEETH)SPROCKET-DRIVEN, REVERSE (42 TEETH)
-
9202292022-1731 WASHER, 28.1X34X1.0WASHER, 28.1X34X1.0
-
9202692026-1066 SPACER, 20.3X30X1.8SPACER, 20.3X30X1.8
-
9203392033-026 RING-SNAP, 24MMRING-SNAP, 24MM
-
92033A92033-1037 RING-SNAP, 25.9X30.6X1.2RING-SNAP, 25.9X30.6X1.2
-
9220092200-1400 WASHER, 24.2X32X0.50WASHER, 24.2X32X0.50
