09- Luggage Rack для BRP Ski-Doo Summit Adrenaline 600HO SDI - 2008

-
№АртикулНазвание
-
1511000510 Light SupportLight Support
-
2250000146 Truss Head Torx Screw K50 X 16Truss Head Torx Screw K50 X 16
-
3250000113 Screw M4 X 16, Type K-40Screw M4 X 16, Type K-40
-
4293750009 Tie-Rap 160 mmTie-Rap 160 mm
-
5511000459 Rear ReflectorRear Reflector
-
6511000460 Rear ReflectorRear Reflector
-
7511000507 Rear light Ass'y. Includes 7 to 10Rear light Ass'y. Includes 7 to 10
-
8710000652 Rear Lens BoxRear Lens Box
-
9710000653 BulbBulb
-
10511000508 Wiring HarnessWiring Harness
-
11705001119 WasherWasher
-
12511000509 Hitch Ass'y. Europe, Includes 12 to 19Hitch Ass'y. Europe, Includes 12 to 19
-
13511000514 Pawl. EuropePawl. Europe
-
14517152800 Spring. EuropeSpring. Europe
-
15114045200 Hair Pin. EuropeHair Pin. Europe
-
16207063544 Hex. Flanged Screw M6 X 35. EuropeHex. Flanged Screw M6 X 35. Europe
-
17232561414 Elastic Stop Nut M6. EuropeElastic Stop Nut M6. Europe
-
18732804000 Spring Pin M3 X 24. EuropeSpring Pin M3 X 24. Europe
-
19516003037 Security Label. EuropeSecurity Label. Europe
-
20205484546 Socket Head Screw M8 X 45. EuropeSocket Head Screw M8 X 45. Europe
-
21233281414 Hex. Flanged Elastic Nut M8. EuropeHex. Flanged Elastic Nut M8. Europe
-
22516002960 Warning Label, Maximum Cargo LoadWarning Label, Maximum Cargo Load
-
23293550004 Dielectric Grease, 150 gDielectric Grease, 150 g
