09- Luggage Rack RENX для BRP Ski-Doo MX Z Renegade X 600 HO SDI - 2007
-
№АртикулНазвание
-
1511000513 Light SupportLight Support
-
2250000146 Truss Head Torx Screw K50 X 16Truss Head Torx Screw K50 X 16
-
3250000113 Screw M4 X 16, Type K-40Screw M4 X 16, Type K-40
-
4293750009 Tie-Rap 160 mmTie-Rap 160 mm
-
5511000459 Rear ReflectorRear Reflector
-
6511000460 Rear ReflectorRear Reflector
-
7710000652 Rear Lens BoxRear Lens Box
-
8710000653 BulbBulb
-
9511000508 Wiring HarnessWiring Harness
-
10705001119 WasherWasher
-
11511000518 Support. EuropeSupport. Europe
-
12511000514 Pawl. EuropePawl. Europe
-
13517152800 Spring. EuropeSpring. Europe
-
14114045200 Hair Pin. EuropeHair Pin. Europe
-
15207063544 Hex. Flanged Screw M6 X 35. EuropeHex. Flanged Screw M6 X 35. Europe
-
16232561414 Elastic Stop Nut M6. EuropeElastic Stop Nut M6. Europe
-
17732804000 Spring Pin M3 X 24. EuropeSpring Pin M3 X 24. Europe
-
18516003037 Security Label. EuropeSecurity Label. Europe
-
19205484546 Socket Head Screw M8 X 45. EuropeSocket Head Screw M8 X 45. Europe
-
20233281414 Hex Flanged Elastic Nut M8. EuropeHex Flanged Elastic Nut M8. Europe
-
21516002960 Warning Label, Maximum Cargo LoadWarning Label, Maximum Cargo Load
-
22293550004 Dielectric Grease, 150 gDielectric Grease, 150 g
