01- Cylinder And Crankshaft для BRP Lynx YETI SUV V-800 - 2006

  • №
    Артикул
    Название
  • -
    420819359 Crankshaft + conrod ass’y. Includes 1 to 5
    Crankshaft + conrod ass’y. Includes 1 to 5
  • 1
    420819355 Crankshaft ass'y
    Crankshaft ass'y
  • 2
    420246570 Woodruff key
    Woodruff key
  • 3
    420217425 Conrod. Includes 3 to 4
    Conrod. Includes 3 to 4
  • 4
    420641640 Screw M8
    Screw M8
  • 5
    420233980 Bearing half
    Bearing half
  • 6
    420296775 Piston ass'y 90,958 mm. Includes 6 to 7
    Piston ass'y 90,958 mm. Includes 6 to 7
  • 6
    420296776 Piston ass'y 91,208 mm (oversize). Includes 6 to 7
    Piston ass'y 91,208 mm (oversize). Includes 6 to 7
  • 7
    420296774 Piston ring set
    Piston ring set
  • 8
    420216270 Piston pin
    Piston pin
  • 9
    420845106 Monohook circlip
    Monohook circlip
  • 10
    420630210 Gasket
    Gasket
  • 11
    420613587 Cylinder with sleeve. Includes 11 to 12
    Cylinder with sleeve. Includes 11 to 12
  • 12
    420929650 Drive pin
    Drive pin
  • 13
    420684132 Gasket set
    Gasket set
  • 14
    420929650 Engine oil, 0W40, 12 x 1 liter
    Engine oil, 0W40, 12 x 1 liter
