01- Crankshaft, Pistons And Cylinder для BRP Traxter, 7459/7460/7465/7466 - 2001
-
№АртикулНазвание
-
1290632010 Pin M8 x 12Pin M8 x 12
-
2711941126 Screw Hex.Flanged M6 x 35Screw Hex.Flanged M6 x 35
-
3711650430 Gasket, CylinderGasket, Cylinder
-
4711613177 Cylinder/Piston. Includes 4 - 6.Cylinder/Piston. Includes 4 - 6.
-
5711296110 Piston 89 mm & Ring Set. Includes 5 - 6.Piston 89 mm & Ring Set. Includes 5 - 6.
-
6711296114 Piston Ring SetPiston Ring Set
-
7711216225 Piston PinPiston Pin
-
8711245431 Circlip 22 mmCirclip 22 mm
-
9711295893 Crankshaft Ass'y. Includes 9 - 10.Crankshaft Ass'y. Includes 9 - 10.
-
10711247070 SpacerSpacer
-
11711635011 Mating Gear (42 Teeth)Mating Gear (42 Teeth)
-
12711842605 Nut Hex. M34Nut Hex. M34
-
13711220470 Balance ShaftBalance Shaft
-
14711635100 Balancing Gear DoubleBalancing Gear Double
-
15707000008 Spark Plug (NGK/DR8EA)Spark Plug (NGK/DR8EA)
-
16290945757 Lock Washer 18 mmLock Washer 18 mm
-
17420942220 Nut Hex. M18Nut Hex. M18
-
18711220462 Cam ShaftCam Shaft
-
19711634956 Cam Shaft Gear (38 Teeth)Cam Shaft Gear (38 Teeth)
-
20420232420 Needle PinNeedle Pin
-
21711220615 Deko Shaft Ass'y. Includes 21 - 22.Deko Shaft Ass'y. Includes 21 - 22.
-
23711231050 Centrifugal WeightCentrifugal Weight
-
24711239570 Tension SpringTension Spring
-
25711244260 RondelleRondelle
-
26420945752 Lock Washer 8 mmLock Washer 8 mm
-
27207084044 Screw Hex. M8 x 40Screw Hex. M8 x 40
-
28711951760 ClampClamp
-
29711222285 Water Cooling HoseWater Cooling Hose
-
30711427505 Adjusting Washer 35 x 45 x 1.3Adjusting Washer 35 x 45 x 1.3
-
711427506 Adjusting Washer 35 x 45 x 1.5Adjusting Washer 35 x 45 x 1.5
-
711427507 Adjusting Washer 35 x 45 x 1.8Adjusting Washer 35 x 45 x 1.8
-
31711974644 Bayonet Filler Cap. Includes 31 - 32.Bayonet Filler Cap. Includes 31 - 32.
-
32711650990 Gasket RingGasket Ring
-
33711260050 Rubber BushingRubber Bushing
-
34711211835 Valve CoverValve Cover
-
35711650450 Gasket, Valve CoverGasket, Valve Cover
-
36711854575 Push RodPush Rod
-
37711254083 Rocker ArmRocker Arm
-
38711253090 Valve CotterValve Cotter
-
39711254100 Retainer, Valve SpringRetainer, Valve Spring
-
40711239500 Valve SpringValve Spring
-
41420230810 Valve SealValve Seal
-
42711227980 Thrust WasherThrust Washer
-
43711222425 Temperature SensorTemperature Sensor
-
44711241751 Screw Hex.Flanged M6 x 16Screw Hex.Flanged M6 x 16
-
45711241751 Screw Hex. M6 x 16Screw Hex. M6 x 16
-
46404146600 Seal WasherSeal Washer
-
47711222560 Thermostat CoverThermostat Cover
-
48711222495 Thermostat. Includes 48 - 49.Thermostat. Includes 48 - 49.
-
49711650300 Gasket ThermostatGasket Thermostat
-
50233101414 Hex. Nut M10Hex. Nut M10
-
51711613375 Cylinder HeadCylinder Head
-
52711650446 Gasket, Cylinder HeadGasket, Cylinder Head
-
53711254050 Inlet Valve 42 mmInlet Valve 42 mm
-
54711254062 Inlet Valve 34 mmInlet Valve 34 mm
-
55711854090 Hydraulic Valve TappetHydraulic Valve Tappet
-
56420240326 Screw Hex. Flanged M8 x 53,5Screw Hex. Flanged M8 x 53,5
-
57711940366 Stud M8 x 23Stud M8 x 23
-
58711254110 Rocker Arm ShaftRocker Arm Shaft
-
59711244250 Holding StripHolding Strip
-
60711241681 Socket Screw M6 x 10Socket Screw M6 x 10
-
61293800060 Loctite 243, 10 mlLoctite 243, 10 ml
-
62278000998 Female Terminal AmpFemale Terminal Amp
-
63293800023 Loctite 767, Antiseize Lubricant, 454 gLoctite 767, Antiseize Lubricant, 454 g
-
64293800070 Loctite Antiseize, 8 ozLoctite Antiseize, 8 oz
-
65420922245 Fitting 90 DegFitting 90 Deg
-
66278001005 Female Housing 2 Circ. BoschFemale Housing 2 Circ. Bosch
-
67711246570 Woodruff KeyWoodruff Key
-
68711296372 Gasket Set EngineGasket Set Engine
-
69711240901 Screw Hex. M6 x 47,9Screw Hex. M6 x 47,9
-
70711222610 Formed HoseFormed Hose
-
71711874380 Y-FittingY-Fitting
-
72711222590 FittingFitting
-
73711222600 Formed HoseFormed Hose
-
74711251222 Gear ClampGear Clamp
-
75413711400 Loctite Green 648, 10 mlLoctite Green 648, 10 ml
-
77278000999 Seal AmpSeal Amp
