REAR SUSPENSION FRONT ARM SHOCK ABSORBER для Arctic Cat ZR 9000 THUNDERCAT 137 BLACK EARLY BUILD - 2018 года выпуска

  • №
    Артикул
    Название
  • 1
    2704-705 SHOCK ABSORBER (INC. 2-29)
    SHOCK ABSORBER (INC. 2-29)
  • 2
    3604-797 ...EYELET, SHOCK
    ...EYELET, SHOCK
  • 3
    3604-831 ...ROD, SHOCK
    ...ROD, SHOCK
  • 4
    4604-125 ...BEARING, ENDCAP - ASSEMBLY
    ...BEARING, ENDCAP - ASSEMBLY
  • 5
    4604-121 ...KIT, SEAL/REBUILD
    ...KIT, SEAL/REBUILD
  • 6
    3604-789 ...WASHER, TOP OUT
    ...WASHER, TOP OUT
  • 7
    3603-096 ...VALVE, 0.700 X 0.012 IN.
    ...VALVE, 0.700 X 0.012 IN.
  • 8
    3603-105 ...VALVE, 0.800 X 0.010 IN.
    ...VALVE, 0.800 X 0.010 IN.
  • 9
    3603-114 ...VALVE, 0.900 X 0.008 IN.
    ...VALVE, 0.900 X 0.008 IN.
  • 10
    3603-124 ...VALVE, 1.000 X 0.008 IN.
    ...VALVE, 1.000 X 0.008 IN.
  • 11
    3603-144 ...VALVE, 1.100 X 0.008 IN.
    ...VALVE, 1.100 X 0.008 IN.
  • 12
    3603-184 ...VALVE, 1.300 X 0.008 IN.
    ...VALVE, 1.300 X 0.008 IN.
  • 13
    3604-790 ...PISTON, 37 BORE-2.35 ORIFICE
    ...PISTON, 37 BORE-2.35 ORIFICE
  • 14
    3603-174 ...VALVE, 1.250 X 0.008 IN.
    ...VALVE, 1.250 X 0.008 IN.
  • 15
    3603-145 ...VALVE, 1.100 X 0.010 IN.
    ...VALVE, 1.100 X 0.010 IN.
  • 16
    3603-125 ...VALVE, 1.000 X 0.010 IN.
    ...VALVE, 1.000 X 0.010 IN.
  • 17
    3603-115 ...VALVE, 0.900 X 0.010 IN.
    ...VALVE, 0.900 X 0.010 IN.
  • 18
    3604-775 ...WASHER, BACKUP
    ...WASHER, BACKUP
  • 19
    3604-739 ...NUT
    ...NUT
  • 20
    3604-772 ...PISTON, FLOATING
    ...PISTON, FLOATING
  • 21
    3604-773 ...SLEEVE, WEAR
    ...SLEEVE, WEAR
  • 22
    3603-618 ...NUT, ADJUSTER
    ...NUT, ADJUSTER
  • 23
    3604-830 ...BODY, SHOCK
    ...BODY, SHOCK
  • 24
    1621-728 ...DECAL, WARNING - HIGH PRESSURE
    ...DECAL, WARNING - HIGH PRESSURE
  • 25
    2704-257 ...END CAP, SHOCK - ASSEMBLY (INC. 26-27)
    ...END CAP, SHOCK - ASSEMBLY (INC. 26-27)
  • 26
    3604-751 ......VALVE, PRESSURE (INC. 27)
    ......VALVE, PRESSURE (INC. 27)
  • 27
    3604-733 .........O-RING, VALVE
    .........O-RING, VALVE
  • 28
    3604-750 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 29
    3604-906 ...BEARING
    ...BEARING
  • 30
    5639-530 OIL, SHOCK - 1 QT
    OIL, SHOCK - 1 QT
  • 31
    0604-790 COVER, SHOCK
    COVER, SHOCK
  • 32
    1704-736 SPRING, COMPRESSION - BLACK
    SPRING, COMPRESSION - BLACK
  • 33
    3604-200 RETAINER, SPRING
    RETAINER, SPRING
  • 34
    3604-273 AXLE
    AXLE
  • 35
    8408-045 SCREW, CAP
    SCREW, CAP
  • S
    2623-202 NUT, LOCK W/WASHER
    NUT, LOCK W/WASHER
