OIL TANK ASSEMBLY для Arctic Cat M 8000 MOUNTAIN CAT 162 BLACK EARLY BUILD - 2018 года выпуска

  • №
    Артикул
    Название
  • 1
    2670-447 CAP, OIL TANK
    CAP, OIL TANK
  • 2
    1623-969 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 3
    2670-329 NECK, OIL FILL
    NECK, OIL FILL
  • 4
    2623-158 O-RING
    O-RING
  • 5
    0621-786 DECAL, OIL TANK
    DECAL, OIL TANK
  • 6
    1623-814 SCREW, MACHINE
    SCREW, MACHINE
  • 7
    1770-214 TANK, OIL (INC. 8-11)
    TANK, OIL (INC. 8-11)
  • 8
    2623-007 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 9
    2670-558 ...PLATE, BAFFLE - UPPER
    ...PLATE, BAFFLE - UPPER
  • 10
    2670-559 ...PLATE, BAFFLE - LOWER
    ...PLATE, BAFFLE - LOWER
  • 11
    0913-021 ...FITTING, ELBOW
    ...FITTING, ELBOW
  • 12
    0609-915 SWITCH, LEVEL - OIL (INC. 13)
    SWITCH, LEVEL - OIL (INC. 13)
  • 13
    0609-924 ...GROMMET
    ...GROMMET
  • 14
    1623-351 CLAMP, HOSE
    CLAMP, HOSE
  • 15
    0610-968 HOSE - CLEAR - 25 FT
    HOSE - CLEAR - 25 FT
  • 16
    0716-558 CONDUIT, PROTECTIVE - 10 FT
    CONDUIT, PROTECTIVE - 10 FT
  • 17
    2670-362 T-FITTING
    T-FITTING
  • 18
    1619-359 CONDUIT, FLEXIBLE - 5 FT
    CONDUIT, FLEXIBLE - 5 FT
  • 19
    2623-013 CLAMP, HOSE
    CLAMP, HOSE
  • 20
    0610-967 HOSE - GREEN - 25 FT
    HOSE - GREEN - 25 FT
  • 21
    5706-536 CONDUIT, FLEXIBLE - 5 FT
    CONDUIT, FLEXIBLE - 5 FT
  • 22
    2623-246 CLAMP, HOSE
    CLAMP, HOSE
  • 23
    1623-655 CLAMP, HOSE
    CLAMP, HOSE
  • 24
    8468-613 SCREW, CAP
    SCREW, CAP
  • 25
    0912-005 PUMP, OIL (INC. 26)
    PUMP, OIL (INC. 26)
  • 26
    0930-046 ...O-RING
    ...O-RING
  • 27
    0923-050 CLAMP, HOSE
    CLAMP, HOSE
  • 28
    1619-356 CONDUIT, HIGH TEMP
    CONDUIT, HIGH TEMP
  • 29
    0610-966 HOSE - CLEAR - 25 FT
    HOSE - CLEAR - 25 FT
  • 30
    1048-063 SEALANT - 70 ML
    SEALANT - 70 ML
  • 31
    0123-903 TIE, CABLE - 11.5 IN.
    TIE, CABLE - 11.5 IN.
  • 32
    2623-176 CLAMP
    CLAMP
