SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat ZR 6000 RS LTD ES 129 BLACK - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    5718-496 PANEL, SIDE W/DECALS - RIGHT - BLACK (INC. 2-11 AND 18-19)
    PANEL, SIDE W/DECALS - RIGHT - BLACK (INC. 2-11 AND 18-19)
  • 2
    5718-306 ...PANEL, SIDE W/O DECALS - RIGHT - BLACK (INC. 3-11)
    ...PANEL, SIDE W/O DECALS - RIGHT - BLACK (INC. 3-11)
  • 3
    3621-487 ......DECAL, WARNING - ENGLISH
    ......DECAL, WARNING - ENGLISH
  • 4
    1623-939 ......NUT, U
    ......NUT, U
  • 5
    2623-166 ......SCREW, SELF-TAPPING
    ......SCREW, SELF-TAPPING
  • 6
    7606-292 ......HOOK, MOUNTING - RIGHT
    ......HOOK, MOUNTING - RIGHT
  • 6
    7606-293 ......HOOK, MOUNTING - LEFT
    ......HOOK, MOUNTING - LEFT
  • 7
    0617-756 ......FOAM, SIDE PANEL - LOWER REAR - RIGHT
    ......FOAM, SIDE PANEL - LOWER REAR - RIGHT
  • 8
    7606-552 ......FOIL, PROTECTIVE - REAR - RIGHT
    ......FOIL, PROTECTIVE - REAR - RIGHT
  • 9
    7606-598 ......FOIL, PROTECTIVE - UPPER - RIGHT
    ......FOIL, PROTECTIVE - UPPER - RIGHT
  • 10
    0617-758 ......FOAM, SIDE PANEL - MID - RIGHT
    ......FOAM, SIDE PANEL - MID - RIGHT
  • 11
    0617-754 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
    ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
  • 12
    5718-497 PANEL, SIDE W/DECALS - LEFT - BLACK (INC. 4-6 AND 13-19)
    PANEL, SIDE W/DECALS - LEFT - BLACK (INC. 4-6 AND 13-19)
  • 13
    5718-031 ...PANEL, SIDE W/WARNING DECAL - LEFT - BLACK (INC. 4-6 AND 14-17)
    ...PANEL, SIDE W/WARNING DECAL - LEFT - BLACK (INC. 4-6 AND 14-17)
  • 14
    3621-486 ......DECAL, WARNING - FRENCH
    ......DECAL, WARNING - FRENCH
  • 15
    0617-757 ......FOAM, SIDE PANEL - LOWER REAR - LEFT
    ......FOAM, SIDE PANEL - LOWER REAR - LEFT
  • 16
    0617-755 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT
    ......FOAM, SIDE PANEL - LOWER FRONT - LEFT
  • 17
    0617-759 ......FOAM, SIDE PANEL - MIDDLE - LEFT
    ......FOAM, SIDE PANEL - MIDDLE - LEFT
  • 18
    3621-908 ...DECAL, SIDE PANEL - LOWER REAR - RIGHT
    ...DECAL, SIDE PANEL - LOWER REAR - RIGHT
  • 18
    3621-909 ...DECAL, SIDE PANEL - LOWER REAR - LEFT
    ...DECAL, SIDE PANEL - LOWER REAR - LEFT
  • 19
    3621-912 ...DECAL, SIDE PANEL - LOWER FRONT - RIGHT
    ...DECAL, SIDE PANEL - LOWER FRONT - RIGHT
  • 19
    3621-913 ...DECAL, SIDE PANEL - LOWER FRONT - LEFT
    ...DECAL, SIDE PANEL - LOWER FRONT - LEFT
  • 20
    2623-211 SCREW
    SCREW
  • 21
    5718-506 PLATE, SKID W/FOAM - RIGHT - BLACK (INC. TWO NO. 4, 22-24, AND 29-34)
    PLATE, SKID W/FOAM - RIGHT - BLACK (INC. TWO NO. 4, 22-24, AND 29-34)
  • 22
    0617-776 ...FOAM, SKID PLATE - FRONT - RIGHT
    ...FOAM, SKID PLATE - FRONT - RIGHT
  • 23
    0617-762 ...FOAM, SKID PLATE - MIDDLE - RIGHT
    ...FOAM, SKID PLATE - MIDDLE - RIGHT
  • 24
    7606-290 ...FOIL, PROTECTIVE - RIGHT
    ...FOIL, PROTECTIVE - RIGHT
  • 25
    4718-971 PLATE, SKID W/O DECALS - LEFT - BLACK (INC. TWO NO. 4 AND 26-34)
    PLATE, SKID W/O DECALS - LEFT - BLACK (INC. TWO NO. 4 AND 26-34)
  • 26
    0617-765 ...FOAM, SKID PLATE - LOWER - LEFT
    ...FOAM, SKID PLATE - LOWER - LEFT
  • 27
    0617-763 ...FOAM, SKID PLATE - MIDDLE - LEFT
    ...FOAM, SKID PLATE - MIDDLE - LEFT
  • 28
    0617-761 ...FOAM, SKID PLATE - FRONT - LEFT
    ...FOAM, SKID PLATE - FRONT - LEFT
  • 29
    7606-265 ...KNOB, HOLDDOWN
    ...KNOB, HOLDDOWN
  • 30
    2623-005 ...CLIP, RETAINING
    ...CLIP, RETAINING
  • 31
    7606-296 ...PLATE, BACKING
    ...PLATE, BACKING
  • 32
    2623-171 ...WASHER, FLAT
    ...WASHER, FLAT
  • 33
    2623-155 ...CLIP, RETAINING
    ...CLIP, RETAINING
  • 34
    1623-933 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 35
    8061-708 RIVET
    RIVET
  • 36
    6606-940 SHIELD, HEAT - ECM
    SHIELD, HEAT - ECM
  • 37
    8408-620 SCREW, CAP
    SCREW, CAP
  • 38
    0730-266 ECM
    ECM
  • 39
    0423-031 NUT, SPEED
    NUT, SPEED
  • 40
    7606-272 VENT, UPPER - SIDE PANEL - RIGHT
    VENT, UPPER - SIDE PANEL - RIGHT
  • 40
    7606-273 VENT, UPPER - SIDE PANEL - LEFT
    VENT, UPPER - SIDE PANEL - LEFT
  • 41
    5718-494 PANEL, UPPER SIDE PANEL W/DECALS - RIGHT (INC. 42-43)
    PANEL, UPPER SIDE PANEL W/DECALS - RIGHT (INC. 42-43)
  • 41
    5718-495 PANEL, UPPER SIDE PANEL W/DECALS - LEFT (INC. 42-43)
    PANEL, UPPER SIDE PANEL W/DECALS - LEFT (INC. 42-43)
  • 42
    7606-152 ...PANEL, UPPER SIDE - RIGHT - BLACK
    ...PANEL, UPPER SIDE - RIGHT - BLACK
  • 42
    7606-153 ...PANEL, UPPER SIDE - LEFT - BLACK
    ...PANEL, UPPER SIDE - LEFT - BLACK
  • 43
    3621-906 ...DECAL, UPPER SIDE PANEL - RIGHT
    ...DECAL, UPPER SIDE PANEL - RIGHT
  • 43
    3621-907 ...DECAL, UPPER SIDE PANEL - LEFT
    ...DECAL, UPPER SIDE PANEL - LEFT
