CONSOLE ASSEMBLY для Arctic Cat ZR 6000 R XC GREEN - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    6706-445 CONSOLE - BLACK
    CONSOLE - BLACK
  • 2
    0630-243 ALARM, REVERSE (INC. 3)
    ALARM, REVERSE (INC. 3)
  • 3
    0630-017 ...RING, RETAINING
    ...RING, RETAINING
  • 4
    0123-985 WASHER, INTERNAL TOOTH LOCK
    WASHER, INTERNAL TOOTH LOCK
  • 5
    0709-071 TETHER SWITCH (INC. 6-7)
    TETHER SWITCH (INC. 6-7)
  • 6
    0709-055 ...TETHER CORD W/ SCREW (INC. 7)
    ...TETHER CORD W/ SCREW (INC. 7)
  • 7
    0623-338 ......SCREW, SELF-TAPPING
    ......SCREW, SELF-TAPPING
  • 8
    7606-265 KNOB, HOLDDOWN
    KNOB, HOLDDOWN
  • 9
    7606-296 PLATE, BACKING
    PLATE, BACKING
  • 10
    2623-155 CLIP, RETAINING
    CLIP, RETAINING
  • 11
    2623-171 WASHER, FLAT
    WASHER, FLAT
  • 12
    1623-933 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 13
    2623-166 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 14
    2623-164 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
