SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat ZR 4000 LXR 129 BLACK - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    5718-104 PANEL, SIDE - RIGHT W/DECALS - BLACK (INC. 2-7, 13-16, AND 18-21)
    PANEL, SIDE - RIGHT W/DECALS - BLACK (INC. 2-7, 13-16, AND 18-21)
  • 2
    3718-180 ...PANEL, SIDE - RIGHT W/FOAM - BLACK (INC. 3-7 AND 18-21)
    ...PANEL, SIDE - RIGHT W/FOAM - BLACK (INC. 3-7 AND 18-21)
  • 3
    0617-626 ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT
    ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT
  • 4
    6606-414 ......FOIL, PROTECTIVE - MIDDLE PANEL - RIGHT
    ......FOIL, PROTECTIVE - MIDDLE PANEL - RIGHT
  • 5
    0617-628 ......FOAM, SIDE PANEL - UPPER REAR - RIGHT
    ......FOAM, SIDE PANEL - UPPER REAR - RIGHT
  • 6
    0617-632 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
    ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
  • 7
    0617-634 ......FOAM, SIDE PANEL - LOWER REAR - RIGHT
    ......FOAM, SIDE PANEL - LOWER REAR - RIGHT
  • 8
    5718-105 PANEL, SIDE - LEFT W/DECALS - BLACK (INC. 9-21)
    PANEL, SIDE - LEFT W/DECALS - BLACK (INC. 9-21)
  • 9
    4718-553 ...PANEL, SIDE W/FOAM- LEFT - BLACK (INC. 10-12 AND 17-21)
    ...PANEL, SIDE W/FOAM- LEFT - BLACK (INC. 10-12 AND 17-21)
  • 10
    0617-629 ......FOAM, SIDE PANEL - UPPER REAR - LEFT
    ......FOAM, SIDE PANEL - UPPER REAR - LEFT
  • 11
    0617-635 ......FOAM, SIDE PANEL - LOWER REAR - LEFT
    ......FOAM, SIDE PANEL - LOWER REAR - LEFT
  • 12
    0617-681 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT
    ......FOAM, SIDE PANEL - LOWER FRONT - LEFT
  • 13
    3621-268 ...DECAL, SIDE PANEL - UPPER - RIGHT
    ...DECAL, SIDE PANEL - UPPER - RIGHT
  • 13
    3621-269 ...DECAL, SIDE PANEL - UPPER - LEFT
    ...DECAL, SIDE PANEL - UPPER - LEFT
  • 14
    3621-250 ...DECAL, SIDE PANEL - LOWER - RIGHT
    ...DECAL, SIDE PANEL - LOWER - RIGHT
  • 14
    3621-251 ...DECAL, SIDE PANEL - LOWER REAR - LEFT - BLACK
    ...DECAL, SIDE PANEL - LOWER REAR - LEFT - BLACK
  • 15
    3621-254 ...DECAL, SIDE PANEL - FRONT - RIGHT
    ...DECAL, SIDE PANEL - FRONT - RIGHT
  • 15
    3621-255 ...DECAL, SIDE PANEL - FRONT - LEFT
    ...DECAL, SIDE PANEL - FRONT - LEFT
  • 16
    3621-252 ...DECAL, SIDE PANEL - MID - RIGHT
    ...DECAL, SIDE PANEL - MID - RIGHT
  • 16
    3621-257 ...DECAL, SIDE PANEL - VENT - LEFT
    ...DECAL, SIDE PANEL - VENT - LEFT
  • 17
    1623-637 ...CLIP, U-NUT
    ...CLIP, U-NUT
  • 18
    0607-447 ...CABLE
    ...CABLE
  • 19
    0605-283 ...CLIP, HAIRPIN
    ...CLIP, HAIRPIN
  • 20
    8060-486 ...RIVET
    ...RIVET
  • 21
    8050-127 ...WASHER
    ...WASHER
  • 22
    1623-052 CLIP, U-NUT
    CLIP, U-NUT
  • 23
    6606-925 SCREEN, INTAKE
    SCREEN, INTAKE
  • 24
    2602-794 DUCT, INTAKE - INNER
    DUCT, INTAKE - INNER
  • 25
    1623-030 CLIP, U-NUT
    CLIP, U-NUT
  • 26
    2602-793 DUCT, INTAKE - OUTER - BLACK
    DUCT, INTAKE - OUTER - BLACK
  • 27
    5706-531 SCREEN, INTAKE - UPPER - LEFT - BLACK (OPT.)
    SCREEN, INTAKE - UPPER - LEFT - BLACK (OPT.)
  • 28
    0619-206 FOIL, PROTECTIVE (OPT.)
    FOIL, PROTECTIVE (OPT.)
  • 29
    5718-114 PLATE, SKID - RIGHT W/DECAL - BLACK (INC. 30-34 AND 43)
    PLATE, SKID - RIGHT W/DECAL - BLACK (INC. 30-34 AND 43)
  • 30
    4718-520 ...PLATE, SKID - W/O DECALS - RIGHT - BLACK (INC. 31-34)
    ...PLATE, SKID - W/O DECALS - RIGHT - BLACK (INC. 31-34)
  • 31
    0617-640 ......FOAM, SKID PLATE - UPPER REAR - RIGHT
    ......FOAM, SKID PLATE - UPPER REAR - RIGHT
  • 32
    0617-638 ......FOAM, SKID PLATE - CENTER FRONT - RIGHT
    ......FOAM, SKID PLATE - CENTER FRONT - RIGHT
  • 33
    0617-636 ......FOAM, SKID PLATE - UPPER FRONT - RIGHT
    ......FOAM, SKID PLATE - UPPER FRONT - RIGHT
  • 34
    6606-966 ......FOIL, PROTECTIVE - LOWER - RIGHT
    ......FOIL, PROTECTIVE - LOWER - RIGHT
  • 35
    8061-708 RIVET
    RIVET
  • 36
    5718-115 PLATE, SKID - W/DECAL - LEFT - BLACK (INC. 35 AND 37-43)
    PLATE, SKID - W/DECAL - LEFT - BLACK (INC. 35 AND 37-43)
  • 37
    3718-789 ...PLATE, SKID - LEFT W/FOAM - BLACK (INC. 35 AND 38-42)
    ...PLATE, SKID - LEFT W/FOAM - BLACK (INC. 35 AND 38-42)
  • 38
    0617-637 ......FOAM, SKID PLATE - UPPER FRONT - LEFT
    ......FOAM, SKID PLATE - UPPER FRONT - LEFT
  • 39
    0617-639 ......FOAM, SKID PLATE - CENTER FRONT - LEFT
    ......FOAM, SKID PLATE - CENTER FRONT - LEFT
  • 40
    0617-641 ......FOAM, SKID PLATE - UPPER REAR - LEFT
    ......FOAM, SKID PLATE - UPPER REAR - LEFT
  • 41
    6606-613 ......PANEL, REINFORCEMENT
    ......PANEL, REINFORCEMENT
  • 42
    0123-802 WASHER
    WASHER
  • 43
    3621-264 DECAL, SKID PLATE - RIGHT
    DECAL, SKID PLATE - RIGHT
  • 43
    3621-265 DECAL, SKID PLATE - LEFT
    DECAL, SKID PLATE - LEFT
  • 44
    2623-005 CLIP, RETAINING
    CLIP, RETAINING
  • 45
    6606-592 PIN, RETAINING
    PIN, RETAINING
  • 46
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 47
    8408-612 SCREW, CAP
    SCREW, CAP
  • 48
    0423-577 CLIP, U-NUT
    CLIP, U-NUT
  • 49
    6606-942 SHIELD, HEAT - ECM
    SHIELD, HEAT - ECM
  • 50
    8408-620 SCREW, CAP
    SCREW, CAP
  • 51
    6606-941 BRACKET, MOUNTING - ECM
    BRACKET, MOUNTING - ECM
  • 52
    0423-031 NUT, SPEED
    NUT, SPEED
  • 53
    0623-784 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 54
    6606-342 FASCIA, FRONT - RIGHT - BLACK
    FASCIA, FRONT - RIGHT - BLACK
  • 54
    3718-303 FASCIA, FRONT - LEFT - BLACK (INC. 55)
    FASCIA, FRONT - LEFT - BLACK (INC. 55)
  • 55
    6606-405 ...FOIL, PROTECTIVE FILLER PANEL - LEFT
    ...FOIL, PROTECTIVE FILLER PANEL - LEFT
