SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat ZR 7000 RR 129 [S2016ZRURRUSG] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    4718-792 PANEL, SIDE W/DECALS - RIGHT - GREEN (INC. 2-7, 14-17, AND 24-27)
    PANEL, SIDE W/DECALS - RIGHT - GREEN (INC. 2-7, 14-17, AND 24-27)
  • 2
    3718-860 ...PANEL, SIDE - W/O DECALS - RIGHT - GREEN (INC. 3-7 AND 24-27)
    ...PANEL, SIDE - W/O DECALS - RIGHT - GREEN (INC. 3-7 AND 24-27)
  • 3
    0617-626 ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT
    ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT
  • 4
    6606-414 ......FOIL, PROTECTIVE - MIDDLE - RIGHT
    ......FOIL, PROTECTIVE - MIDDLE - RIGHT
  • 5
    0617-628 ......FOAM, SIDE PANEL - UPPER REAR - RIGHT
    ......FOAM, SIDE PANEL - UPPER REAR - RIGHT
  • 6
    0617-632 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
    ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
  • 7
    6606-416 ......FOIL, PROTECTIVE - REAR - RIGHT
    ......FOIL, PROTECTIVE - REAR - RIGHT
  • 8
    4718-793 PANEL, SIDE W/DECALS - LEFT - GREEN (INC. 9-19 AND 23-27)
    PANEL, SIDE W/DECALS - LEFT - GREEN (INC. 9-19 AND 23-27)
  • 9
    3718-859 ...PANEL, SIDE - W/O DECALS - LEFT - GREEN (INC. 10-13, 18-19, AND 23-27)
    ...PANEL, SIDE - W/O DECALS - LEFT - GREEN (INC. 10-13, 18-19, AND 23-27)
  • 10
    0617-629 ......FOAM, SIDE PANEL - UPPER REAR - LEFT
    ......FOAM, SIDE PANEL - UPPER REAR - LEFT
  • 11
    0617-635 ......FOAM, SIDE PANEL - LOWER REAR - LEFT
    ......FOAM, SIDE PANEL - LOWER REAR - LEFT
  • 12
    0617-631 ......FOAM, SIDE PANEL - CENTER FRONT - LEFT
    ......FOAM, SIDE PANEL - CENTER FRONT - LEFT
  • 13
    0617-681 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT
    ......FOAM, SIDE PANEL - LOWER FRONT - LEFT
  • 14
    2621-358 ...DECAL, SIDE PANEL - UPPER - RIGHT
    ...DECAL, SIDE PANEL - UPPER - RIGHT
  • 14
    2621-359 ...DECAL, SIDE PANEL - UPPER - LEFT
    ...DECAL, SIDE PANEL - UPPER - LEFT
  • 15
    2621-364 ...DECAL, SIDE PANEL - LOWER REAR - RIGHT
    ...DECAL, SIDE PANEL - LOWER REAR - RIGHT
  • 15
    2621-551 ...DECAL, SIDE PANEL - LOWER REAR - LEFT
    ...DECAL, SIDE PANEL - LOWER REAR - LEFT
  • 16
    2621-340 ...DECAL, SIDE PANEL - LOWER FRONT - RIGHT
    ...DECAL, SIDE PANEL - LOWER FRONT - RIGHT
  • 16
    2621-341 ...DECAL, SIDE PANEL - LOWER FRONT - LEFT
    ...DECAL, SIDE PANEL - LOWER FRONT - LEFT
  • 17
    2621-344 ...DECAL, SIDE PANEL - CENTER - RIGHT
    ...DECAL, SIDE PANEL - CENTER - RIGHT
  • 17
    2621-345 ...DECAL, SIDE PANEL - CENTER - LEFT
    ...DECAL, SIDE PANEL - CENTER - LEFT
  • 18
    2602-704 ...SCREEN, VENT
    ...SCREEN, VENT
  • 19
    0623-269 ...CLIP, RETAINER
    ...CLIP, RETAINER
  • 20
    2602-711 DEFLECTOR, AIR
    DEFLECTOR, AIR
  • 21
    0623-797 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 22
    2602-703 RETAINER, AIR DEFLECTOR
    RETAINER, AIR DEFLECTOR
  • 23
    1623-637 CLIP, U-NUT
    CLIP, U-NUT
  • 24
    0607-447 CABLE
    CABLE
  • 25
    0605-283 CLIP, HAIRPIN
    CLIP, HAIRPIN
  • 26
    8060-486 RIVET
    RIVET
  • 27
    8050-127 WASHER
    WASHER
  • 28
    0619-206 FOIL, PROTECTIVE
    FOIL, PROTECTIVE
  • 29
    5706-531 SCREEN, INTAKE
    SCREEN, INTAKE
  • 30
    1702-369 DUCT, AIR - CLUTCH
    DUCT, AIR - CLUTCH
  • 31
    1623-030 CLIP, U-NUT
    CLIP, U-NUT
  • 32
    4718-814 PLATE, SKID W/DECALS - RIGHT - GREEN (INC. 33-36 AND 45-46)
    PLATE, SKID W/DECALS - RIGHT - GREEN (INC. 33-36 AND 45-46)
  • 33
    3718-788 ...PLATE, SKID - W/O DECALS - RIGHT - BLACK (INC. 34-36)
    ...PLATE, SKID - W/O DECALS - RIGHT - BLACK (INC. 34-36)
  • 34
    0617-640 ......FOAM, SKID PLATE - UPPER REAR - RIGHT
    ......FOAM, SKID PLATE - UPPER REAR - RIGHT
  • 35
    0617-638 ......FOAM, SKID PLATE - CENTER FRONT - RIGHT
    ......FOAM, SKID PLATE - CENTER FRONT - RIGHT
  • 36
    0617-636 ......FOAM, SKID PLATE - UPPER FRONT - RIGHT
    ......FOAM, SKID PLATE - UPPER FRONT - RIGHT
  • 37
    8061-708 RIVET
    RIVET
  • 38
    4718-801 PLATE, SKID - W/DECALS - LEFT - BLACK (INC. 37 AND 39-46)
    PLATE, SKID - W/DECALS - LEFT - BLACK (INC. 37 AND 39-46)
  • 39
    3718-789 ...PLATE, SKID - W/O DECALS - LEFT - BLACK (INC. 37 AND 40-44)
    ...PLATE, SKID - W/O DECALS - LEFT - BLACK (INC. 37 AND 40-44)
  • 40
    0617-637 ......FOAM, SKID PLATE - UPPER FRONT - LEFT
    ......FOAM, SKID PLATE - UPPER FRONT - LEFT
  • 41
    0617-639 ......FOAM, SKID PLATE - CENTER FRONT - LEFT
    ......FOAM, SKID PLATE - CENTER FRONT - LEFT
  • 42
    0617-641 ......FOAM, SKID PLATE - UPPER REAR - LEFT
    ......FOAM, SKID PLATE - UPPER REAR - LEFT
  • 43
    0123-802 ...WASHER
    ...WASHER
  • 44
    6606-613 PANEL, REINFORCEMENT
    PANEL, REINFORCEMENT
  • 45
    2621-336 DECAL, SKID PLATE - REAR - RIGHT
    DECAL, SKID PLATE - REAR - RIGHT
  • 45
    2621-337 DECAL, SKID PLATE - REAR - LEFT
    DECAL, SKID PLATE - REAR - LEFT
  • 46
    2621-338 DECAL, SKID PLATE - FORWARD - RIGHT
    DECAL, SKID PLATE - FORWARD - RIGHT
  • 46
    2621-339 DECAL, SKID PLATE - FORWARD - LEFT
    DECAL, SKID PLATE - FORWARD - LEFT
  • 47
    2623-005 CLIP, RETAINING
    CLIP, RETAINING
  • 48
    6606-592 PIN, RETAINING
    PIN, RETAINING
  • 49
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 50
    2612-685 PLATE, EXHAUST OUTLET
    PLATE, EXHAUST OUTLET
  • 51
    2612-964 SEAL, EXHAUST OUTLET
    SEAL, EXHAUST OUTLET
  • 52
    8061-508 RIVET
    RIVET
  • 53
    6606-342 FASCIA, FRONT - RIGHT - BLACK
    FASCIA, FRONT - RIGHT - BLACK
  • 53
    6606-579 FASCIA, FRONT - LEFT - BLACK
    FASCIA, FRONT - LEFT - BLACK
  • 54
    0623-784 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 55
    2623-001 NUT, PUSH
    NUT, PUSH
  • 56
    1623-999 SCREW, THUMB
    SCREW, THUMB
