SKI AND SPINDLE ASSEMBLY для Arctic Cat ZR 6000 R XC GREEN [S2016ACDCCUSG] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    3703-402 SPINDLE, STEERING - RIGHT (INC. 2)
    SPINDLE, STEERING - RIGHT (INC. 2)
  • 1
    3703-403 SPINDLE, STEERING - LEFT (INC. 2)
    SPINDLE, STEERING - LEFT (INC. 2)
  • 2
    0603-158 ...BEARING
    ...BEARING
  • 3
    2603-813 AXLE, SPINDLE
    AXLE, SPINDLE
  • 4
    3603-468 SPACER
    SPACER
  • 5
    3603-245 DAMPER, SKI
    DAMPER, SKI
  • 6
    2603-599 SKI, PLASTIC - BLACK
    SKI, PLASTIC - BLACK
  • 7
    2603-746 INSERT
    INSERT
  • 8
    2603-598 HANDLE, PLASTIC SKI - BLACK
    HANDLE, PLASTIC SKI - BLACK
  • 9
    8047-366 NUT, LOCK
    NUT, LOCK
  • 10
    1623-689 SCREW, MACHINE
    SCREW, MACHINE
  • 11
    1623-688 SCREW, MACHINE
    SCREW, MACHINE
  • 12
    0703-871 WEARBAR
    WEARBAR
  • 13
    8047-486 NUT, LOCK
    NUT, LOCK
  • 14
    0423-744 NUT, LOCK
    NUT, LOCK
  • 15
    1623-801 WASHER
    WASHER
  • 16
    0123-458 PIN, COTTER
    PIN, COTTER
  • 17
    1623-781 BOLT, SKI-HFH M10- 1.25 X 137 CL10.9
    BOLT, SKI-HFH M10- 1.25 X 137 CL10.9
