REAR SUSPENSION REAR ARM ASSEMBLY для Arctic Cat ZR 6000 R XC GREEN [S2016ACDCCUSG] - 2016 года выпуска
-
№АртикулНазвание
-
12704-320 ARM, REAR - BLACK (INC. ONE NO. 2)ARM, REAR - BLACK (INC. ONE NO. 2)
-
21623-010 ...FITTING, GREASE...FITTING, GREASE
-
33604-965 AXLEAXLE
-
48413-031 SCREW, CAPSCREW, CAP
-
58408-041 SCREW, CAPSCREW, CAP
-
62704-533 ARM, IDLER - BLACK (INC. 7, 9 AND ONE NO. 2)ARM, IDLER - BLACK (INC. 7, 9 AND ONE NO. 2)
-
72603-481 BEARINGBEARING
-
82704-948 SHOCK ABSORBERSHOCK ABSORBER
-
90104-386 BUSHINGBUSHING
-
103604-638 AXLEAXLE
-
111604-204 BLOCK, SPRING ADJUSTER - RIGHT - BLACKBLOCK, SPRING ADJUSTER - RIGHT - BLACK
-
111604-205 BLOCK, SPRING ADJUSTER - LEFT - BLACKBLOCK, SPRING ADJUSTER - LEFT - BLACK
-
120623-138 RING, RETAININGRING, RETAINING
-
133604-819 SLEEVE, SPRINGSLEEVE, SPRING
-
142704-382 SPRING, SUSPENSION - RIGHTSPRING, SUSPENSION - RIGHT
-
142704-383 SPRING, SUSPENSION - LEFTSPRING, SUSPENSION - LEFT
-
153604-616 WHEEL, IDLER (INC. 16-17)WHEEL, IDLER (INC. 16-17)
-
163604-257 ...BEARING...BEARING
-
173604-256 ...RING, RETAINING...RING, RETAINING
-
183604-289 SPACER, PIVOT - IDLER ARMSPACER, PIVOT - IDLER ARM
-
193604-979 AXLE, OFFSET ARMAXLE, OFFSET ARM
-
203604-930 WASHERWASHER
-
212704-944 PIVOT - IDLER ARM (INC. 22-23)PIVOT - IDLER ARM (INC. 22-23)
-
228408-051 ...SCREW, CAP...SCREW, CAP
-
233604-713 ...BUSHING, FLARED...BUSHING, FLARED
-
242623-002 SCREW, CAPSCREW, CAP
-
252623-076 NUT, LOCK - W/WASHERNUT, LOCK - W/WASHER
-
268408-045 SCREW, CAPSCREW, CAP
-
272704-230 LINK, SHOCK (INC. 28)LINK, SHOCK (INC. 28)
-
283604-266 ...INSERT, RAIL...INSERT, RAIL
-
298408-090 SCREW, CAPSCREW, CAP
-
303604-694 AXLEAXLE
-
313604-804 BUSHINGBUSHING
-
323604-802 SLEEVESLEEVE
