WINDSHIELD AND INSTRUMENTS ASSEMBLIES для Arctic Cat ZR 6000 SNO PRO ES (ORANGE) [S2015ZRDSPUSO] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    4718-384 POD W/DECALS - BLACK (INC. 2-3)
    POD W/DECALS - BLACK (INC. 2-3)
  • 2
    6606-313 ...POD, INSTRUMENT - BLACK
    ...POD, INSTRUMENT - BLACK
  • 3
    1621-460 ...DECAL, POD - RIGHT
    ...DECAL, POD - RIGHT
  • 3
    1621-461 ...DECAL, POD - LEFT
    ...DECAL, POD - LEFT
  • 4
    0641-897 OUTLET, ACCESSORY - 12V
    OUTLET, ACCESSORY - 12V
  • 5
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 6
    0608-736 SCREEN, INTAKE - INJECTION MOLD - RIGHT
    SCREEN, INTAKE - INJECTION MOLD - RIGHT
  • 6
    0608-737 SCREEN, INTAKE - INJECTION MOLD - LEFT
    SCREEN, INTAKE - INJECTION MOLD - LEFT
  • 7
    6606-556 VENT
    VENT
  • 8
    0609-910 SWITCH, IGNITION (INC. 9-11)
    SWITCH, IGNITION (INC. 9-11)
  • 9
    0430-050 ...NUT, FLANGE - IGNITION SWITCH
    ...NUT, FLANGE - IGNITION SWITCH
  • 10
    0430-042 ...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)
    ...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)
  • 10
    0430-043 ...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)
    ...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)
  • 11
    0430-054 ...COVER, KEY
    ...COVER, KEY
  • 12
    0620-389 GAUGE, SPEEDOMETER
    GAUGE, SPEEDOMETER
  • 13
    6606-288 BRACKET, SPEEDOMETER GAUGE - CENTER
    BRACKET, SPEEDOMETER GAUGE - CENTER
  • 14
    8427-602 NUT, LOCK
    NUT, LOCK
  • 15
    8053-212 WASHER, LOCK
    WASHER, LOCK
  • 16
    8410-616 SCREW, CAP
    SCREW, CAP
  • 17
    6606-130 BRACKET, SPEEDOMETER GAUGE - RIGHT
    BRACKET, SPEEDOMETER GAUGE - RIGHT
  • 17
    6606-131 BRACKET, SPEEDOMETER GAUGE - LEFT
    BRACKET, SPEEDOMETER GAUGE - LEFT
  • 18
    0423-355 SCREW, SHOULDER
    SCREW, SHOULDER
  • 19
    1623-764 NUT, EXPANSION
    NUT, EXPANSION
  • 20
    6606-482 WINDSHIELD - LOW - ORANGE
    WINDSHIELD - LOW - ORANGE
  • 21
    8477-516 SCREW, MACHINE
    SCREW, MACHINE
