REAR SUSPENSION ARM ASSEMBLY для Arctic Cat ZR 120 (RUSSIAN) (BLACK) [S2015ZRAAARUB] - 2015 года выпуска`

№

Артикул

Название
1

2704-016 ARM, REAR SUSPENSION (INC. 2)

ARM, REAR SUSPENSION (INC. 2)

18 710 ₽
2

0603-083 ...BEARING,GARLOCK 10DU12

...BEARING,GARLOCK 10DU12

1 240 ₽
3

3604-606 AXLE, LOWER

AXLE, LOWER

4 360 ₽
4

1623-566 SCREW,CAP-HFH 5/16-18 X0.875 G5 W/2353

SCREW,CAP-HFH 5/16-18 X0.875 G5 W/2353

250 ₽
5

3604-605 AXLE, IDLER

AXLE, IDLER

5 190 ₽
6

1604-715 SLEEVE, SPRING

SLEEVE, SPRING

2 280 ₽
7

0704-894 SPRING, SUSPENSION - RIGHT - PAINTED (BLACK)

SPRING, SUSPENSION - RIGHT - PAINTED (BLACK)

11 640 ₽
7

0704-895 SPRING, SUSPENSION - LEFT - PAINTED (BLACK)

SPRING, SUSPENSION - LEFT - PAINTED (BLACK)

11 640 ₽
8

1604-204 BLOCK, SPRING ADJUSTER - RIGHT - (BLACK)

BLOCK, SPRING ADJUSTER - RIGHT - (BLACK)

2 910 ₽
8

1604-205 BLOCK, SPRING ADJUSTER - LEFT - (BLACK)

BLOCK, SPRING ADJUSTER - LEFT - (BLACK)

2 910 ₽
9

0623-138 RING,RETAINING-ADJ BLOCK 9/16

RING,RETAINING-ADJ BLOCK 9/16

110 ₽
10

8047-366 NUT,HEX FLG-NY LOCK 1/4-20 GR F Z & Y

NUT,HEX FLG-NY LOCK 1/4-20 GR F Z & Y

60 ₽
11

1604-708 STRAP, LIMITER

STRAP, LIMITER

3 740 ₽
12

8002-042 SCREW,CAP-HH 1/4-20 X1.00 G5 Z & Y

SCREW,CAP-HH 1/4-20 X1.00 G5 Z & Y

60 ₽
13

8050-222 WASHER,FLAT- 1/4 X .734 X .063 Z & Y

WASHER,FLAT- 1/4 X .734 X .063 Z & Y

110 ₽
14

1604-564 SPACER,INNER-UPPER IDLER

SPACER,INNER-UPPER IDLER

2 490 ₽
15

0300-180 WHEEL, IDLER

WHEEL, IDLER

7 900 ₽
16

1604-565 SPACER,OUTER-UPPER IDLER

SPACER,OUTER-UPPER IDLER

650 ₽
17

8020-131 SCREW,CAP-HFH 5/16-18 X0.875 G5 Z & Y

SCREW,CAP-HFH 5/16-18 X0.875 G5 Z & Y

230 ₽
