SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat XF 7000 SNO PRO 137 (ORANGE) [S2015XFUSPUSO] - 2015 года выпуска
-
№АртикулНазвание
-
14718-414 PANEL, SIDE W/DECALS - RIGHT - (WHITE) (INC. 2-10)PANEL, SIDE W/DECALS - RIGHT - (WHITE) (INC. 2-10)
-
23718-454 ...PANEL, SIDE W/O DECALS - RIGHT - (WHITE) (INC. 3-7)...PANEL, SIDE W/O DECALS - RIGHT - (WHITE) (INC. 3-7)
-
30617-626 ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT......FOAM, SIDE PANEL - UPPER FRONT - RIGHT
-
46606-414 ......FOIL, PROTECTIVE......FOIL, PROTECTIVE
-
50617-628 ......FOAM, SIDE PANEL - UPPER REAR - RIGHT......FOAM, SIDE PANEL - UPPER REAR - RIGHT
-
60617-632 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
-
76606-416 ......FOIL, PROTECTIVE......FOIL, PROTECTIVE
-
81621-468 ...DECAL, SIDE PANEL - UPPER - RIGHT...DECAL, SIDE PANEL - UPPER - RIGHT
-
91621-470 ...DECAL, SIDE PANEL - LOWER - RIGHT...DECAL, SIDE PANEL - LOWER - RIGHT
-
101621-472 ...DECAL, SIDE PANEL - FORWARD - RIGHT...DECAL, SIDE PANEL - FORWARD - RIGHT
-
114718-415 PANEL, SIDE W/DECALS - LEFT - (WHITE) (INC. 12-21)PANEL, SIDE W/DECALS - LEFT - (WHITE) (INC. 12-21)
-
124718-103 ...PANEL, SIDE W/O DECALS - LEFT - (WHITE) (INC. 13-18)...PANEL, SIDE W/O DECALS - LEFT - (WHITE) (INC. 13-18)
-
130617-629 ......FOAM, SIDE PANEL - UPPER REAR - LEFT......FOAM, SIDE PANEL - UPPER REAR - LEFT
-
140617-635 ......FOAM, SIDE PANEL - LOWER REAR - LEFT......FOAM, SIDE PANEL - LOWER REAR - LEFT
-
150617-631 ......FOAM, SIDE PANEL - CENTER FRONT - LEFT......FOAM, SIDE PANEL - CENTER FRONT - LEFT
-
160617-681 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT......FOAM, SIDE PANEL - LOWER FRONT - LEFT
-
172602-704 ......SCREEN, VENT......SCREEN, VENT
-
180623-269 ......CLIP, RETAINER......CLIP, RETAINER
-
191621-469 ...DECAL, SIDE PANEL - UPPER - LEFT...DECAL, SIDE PANEL - UPPER - LEFT
-
201621-471 ...DECAL, SIDE PANEL - LOWER - LEFT...DECAL, SIDE PANEL - LOWER - LEFT
-
211621-473 ...DECAL, SIDE PANEL - FORWARD - LEFT...DECAL, SIDE PANEL - FORWARD - LEFT
-
221623-637 CLIP, U-NUTCLIP, U-NUT
-
230607-447 CABLE,5"-HAIRPINCABLE,5"-HAIRPIN
-
240605-283 CLIP, HAIRPINCLIP, HAIRPIN
-
258060-486 RIVET, BLIND-DH SS54 ZINCRIVET, BLIND-DH SS54 ZINC
-
268050-127 WASHER,FLAT- #8 X .375 X .049 Z & YWASHER,FLAT- #8 X .375 X .049 Z & Y
-
271702-369 DUCT, AIR - CLUTCHDUCT, AIR - CLUTCH
-
281623-030 NUT,SPEED-#10B U TYPENUT,SPEED-#10B U TYPE
-
290623-797 SCREW,SELF TAP-TSTH 10-12X1/2 WO/GPSCREW,SELF TAP-TSTH 10-12X1/2 WO/GP
-
302602-711 DEFLECTOR, AIRDEFLECTOR, AIR
-
312602-703 RETAINER, AIR DEFLECTORRETAINER, AIR DEFLECTOR
-
323718-788 PLATE, SKID W/O DECALS - RIGHT - (BLACK) (INC. 33-35)PLATE, SKID W/O DECALS - RIGHT - (BLACK) (INC. 33-35)
-
330617-640 ...FOAM, SKID PLATE - UPPER REAR - RIGHT...FOAM, SKID PLATE - UPPER REAR - RIGHT
-
340617-638 ...FOAM, SKID PLATE - CENTER FRONT - RIGHT...FOAM, SKID PLATE - CENTER FRONT - RIGHT
-
350617-636 ...FOAM, SKID PLATE - UPPER FRONT - RIGHT...FOAM, SKID PLATE - UPPER FRONT - RIGHT
-
368061-708 RIVET, BLIND-LF SS66 (BLACK)RIVET, BLIND-LF SS66 (BLACK)
-
373718-789 PLATE, SKID W/O DECALS - LEFT - (BLACK) (INC. 38-42)PLATE, SKID W/O DECALS - LEFT - (BLACK) (INC. 38-42)
-
380617-637 ...FOAM, SKID PLATE - UPPER FRONT - LEFT...FOAM, SKID PLATE - UPPER FRONT - LEFT
-
390617-639 ...FOAM, SKID PLATE - CENTER FRONT - LEFT...FOAM, SKID PLATE - CENTER FRONT - LEFT
-
400617-641 ...FOAM, SKID PLATE - UPPER REAR - LEFT...FOAM, SKID PLATE - UPPER REAR - LEFT
-
410123-802 ...WASHER,FLAT .194X.50X.048...WASHER,FLAT .194X.50X.048
-
426606-613 ...PANEL, REINFORCEMENT...PANEL, REINFORCEMENT
-
432623-005 CLIP, RETAININGCLIP, RETAINING
-
446606-592 PIN,RETAINER-BODY PLASTICPIN,RETAINER-BODY PLASTIC
-
451623-129 SCREW,SELF TAP-TXSTRH #10-12X5/8 TP A BLSCREW,SELF TAP-TXSTRH #10-12X5/8 TP A BL
-
462612-685 PLATE, EXHAUST OUTLETPLATE, EXHAUST OUTLET
-
472612-964 SEAL, EXHAUST OUTLETSEAL, EXHAUST OUTLET
-
488061-508 RIVET,BLIND-LF SS56 (BLACK)RIVET,BLIND-LF SS56 (BLACK)
-
496606-342 FASCIA, FRONT - RIGHT - (BLACK)FASCIA, FRONT - RIGHT - (BLACK)
-
506606-579 FASCIA, FRONT - LEFT - (BLACK)FASCIA, FRONT - LEFT - (BLACK)
-
510623-784 SCREW,SELF TAP-TSTRH #10-12X3/4 TP A (BLACK)SCREW,SELF TAP-TSTRH #10-12X3/4 TP A (BLACK)
-
522623-001 NUT, PUSH (OPTIONAL)NUT, PUSH (OPTIONAL)
-
531623-999 SCREW, THUMB (OPTIONAL)SCREW, THUMB (OPTIONAL)
