STEERING POST ASSEMBLY для Arctic Cat XF 7000 SNO PRO 137 (GREEN) [S2015XFUSPUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    8408-830 SCREW,CAP-HFH M8X1.25X30 CL8.8 Z & Y
    SCREW,CAP-HFH M8X1.25X30 CL8.8 Z & Y
  • 2
    1605-118 CAP, STEERING
    CAP, STEERING
  • 3
    1605-073 RISER,5.5" HANDLEBAR-MACH
    RISER,5.5" HANDLEBAR-MACH
  • 4
    8427-602 NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
    NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
  • 5
    0605-998 PLATE, RETAINING
    PLATE, RETAINING
  • 6
    1605-043 BLOCK, MOUNTING - STEERING POST
    BLOCK, MOUNTING - STEERING POST
  • 7
    1605-156 BLOCK, MOUNTING - STEERING POST
    BLOCK, MOUNTING - STEERING POST
  • 8
    2623-070 SCREW,MACH-TSPNH-M6X1.0X70 CL 8.8 Z & Y
    SCREW,MACH-TSPNH-M6X1.0X70 CL 8.8 Z & Y
  • 9
    1705-309 POST, STEERING
    POST, STEERING
  • 10
    2623-076 WASHER, INTERNAL TOOTH LOCK
    WASHER, INTERNAL TOOTH LOCK
