THROTTLE BODY ASSEMBLY для Arctic Cat M 8000 SNO PRO 153 (ORANGE) [S2015M8HSPUSO] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    3007-890 BODY, THROTTLE - ASSEMBLY (INC. 2-9)
    BODY, THROTTLE - ASSEMBLY (INC. 2-9)
  • 2
    3007-891 ...INJECTOR, FUEL - ASSEMBLY (CIRCLE)
    ...INJECTOR, FUEL - ASSEMBLY (CIRCLE)
  • 2
    3007-892 ...INJECTOR, FUEL - ASSEMBLY (SQUARE)
    ...INJECTOR, FUEL - ASSEMBLY (SQUARE)
  • 2
    3007-893 ...INJECTOR, FUEL - ASSEMBLY (TRIANGLE)
    ...INJECTOR, FUEL - ASSEMBLY (TRIANGLE)
  • 3
    3007-442 ...PIPE, DELIVERY
    ...PIPE, DELIVERY
  • 4
    3005-692 ...O-RING - SET
    ...O-RING - SET
  • 5
    3006-723 ...HOSE
    ...HOSE
  • 6
    3004-193 ...CLAMP, HOSE
    ...CLAMP, HOSE
  • 7
    3007-443 ...SCREW
    ...SCREW
  • 8
    3006-939 ...SENSOR, THROTTLE POSITION - ASSEMBLY
    ...SENSOR, THROTTLE POSITION - ASSEMBLY
  • 9
    3007-026 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 10
    3007-538 ROD, CONTROL
    ROD, CONTROL
