SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat TZ1 Turbo LXR [S2013TZNTXUSB] - 2013 года выпуска
-
№АртикулНазвание
-
13718-800 PANEL, SIDE - UPPER - RIGHT W/DECALS - BLACK (INC. 2-5)PANEL, SIDE - UPPER - RIGHT W/DECALS - BLACK (INC. 2-5)
-
13718-801 PANEL, SIDE - UPPER - LEFT W/DECALS - BLACK (INC. 2-3 AND 5)PANEL, SIDE - UPPER - LEFT W/DECALS - BLACK (INC. 2-3 AND 5)
-
23718-384 ...PANEL, SIDE - UPPER - RIGHT W/O DECALS - BLACK (INC. 3-4)...PANEL, SIDE - UPPER - RIGHT W/O DECALS - BLACK (INC. 3-4)
-
23718-385 ...PANEL, SIDE - UPPER - LEFT W/O DECALS - BLACK (INC. 3)...PANEL, SIDE - UPPER - LEFT W/O DECALS - BLACK (INC. 3)
-
30617-562 ......FOAM, UPPER SIDE PANEL - RIGHT......FOAM, UPPER SIDE PANEL - RIGHT
-
30617-563 ......FOAM, UPPER SIDE PANEL - LEFT......FOAM, UPPER SIDE PANEL - LEFT
-
44606-799 ......FOIL, PROTECTIVE......FOIL, PROTECTIVE
-
59611-778 ...DECAL, UPPER SIDE PANEL - RIGHT...DECAL, UPPER SIDE PANEL - RIGHT
-
59611-779 ...DECAL, UPPER SIDE PANEL - LEFT...DECAL, UPPER SIDE PANEL - LEFT
-
64606-650 VENT, UPPER SIDE PANEL - REAR - RIGHT - BLACKVENT, UPPER SIDE PANEL - REAR - RIGHT - BLACK
-
64606-651 VENT, UPPER SIDE PANEL - REAR - LEFT - BLACKVENT, UPPER SIDE PANEL - REAR - LEFT - BLACK
-
75606-650 VENT, UPPER SIDE PANEL - FRONT - RIGHT - BLACKVENT, UPPER SIDE PANEL - FRONT - RIGHT - BLACK
-
75606-651 VENT, UPPER SIDE PANEL - FRONT - LEFT - BLACKVENT, UPPER SIDE PANEL - FRONT - LEFT - BLACK
-
86606-191 SCREEN, VENTSCREEN, VENT
-
93718-792 PANEL, SIDE - LOWER - RIGHT W/DECALS - BLACK (INC. 10-13)PANEL, SIDE - LOWER - RIGHT W/DECALS - BLACK (INC. 10-13)
-
93718-799 PANEL, SIDE - LOWER - LEFT W/DECALS - BLACK (INC. 10-13)PANEL, SIDE - LOWER - LEFT W/DECALS - BLACK (INC. 10-13)
-
102718-800 ...PANEL, SIDE - LOWER - RIGHT W/O DECALS - BLACK (INC. 11-12)...PANEL, SIDE - LOWER - RIGHT W/O DECALS - BLACK (INC. 11-12)
-
102718-349 ...PANEL, SIDE - LOWER - LEFT W/O DECALS - BLACK (INC. 11-12)...PANEL, SIDE - LOWER - LEFT W/O DECALS - BLACK (INC. 11-12)
-
110617-568 ......FOAM, LOWER SIDE PANEL - REAR - RIGHT......FOAM, LOWER SIDE PANEL - REAR - RIGHT
-
110617-567 ......FOAM, LOWER SIDE PANEL - REAR - LEFT......FOAM, LOWER SIDE PANEL - REAR - LEFT
-
120617-564 ......FOAM, LOWER SIDE PANEL - FRONT - RIGHT......FOAM, LOWER SIDE PANEL - FRONT - RIGHT
-
120617-566 ......FOAM, LOWER SIDE PANEL - FRONT - LEFT......FOAM, LOWER SIDE PANEL - FRONT - LEFT
-
139611-780 ...DECAL, LOWER SIDE PANEL - RIGHT - BLACK...DECAL, LOWER SIDE PANEL - RIGHT - BLACK
-
139611-781 ...DECAL, LOWER SIDE PANEL - LEFT - BLACK...DECAL, LOWER SIDE PANEL - LEFT - BLACK
-
148408-620 SCREW, CAPSCREW, CAP
-
158427-602 NUT, LOCKNUT, LOCK
-
168408-635 SCREW, CAPSCREW, CAP
-
173706-706 PLATE, SKID - RIGHTPLATE, SKID - RIGHT
-
174706-073 PLATE, SKID - LEFTPLATE, SKID - LEFT
-
184606-982 FOIL, SKID PLATE HINGEFOIL, SKID PLATE HINGE
-
194606-796 FOIL, PROTECTIVE - UPPER - FRONT - RIGHTFOIL, PROTECTIVE - UPPER - FRONT - RIGHT
-
204606-798 FOIL, PROTECTIVE - OUTER - RIGHTFOIL, PROTECTIVE - OUTER - RIGHT
-
214606-797 FOIL, PROTECTIVE - CENTER - RIGHTFOIL, PROTECTIVE - CENTER - RIGHT
-
222612-268 SHIELD, HEATSHIELD, HEAT
-
231712-328 PLATE, EXHAUST - OUTLETPLATE, EXHAUST - OUTLET
-
242612-122 SEAL, EXHAUST - OUTLETSEAL, EXHAUST - OUTLET
-
251712-501 SHIELD, HEAT - EXHAUST OUTLETSHIELD, HEAT - EXHAUST OUTLET
-
268060-510 RIVETRIVET
-
278061-508 RIVETRIVET
-
280623-778 RIVETRIVET
-
290623-966 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
308061-708 RIVETRIVET
-
314606-926 STRAP, HOLD-DOWNSTRAP, HOLD-DOWN
