SEAT SUPPORT ASSEMBLY для Arctic Cat F5 LXR (GREEN) - 2012 года выпуска
-
№АртикулНазвание
-
13718-136 SPAR, REAR W/DECALS - RIGHT - BLACK (INC. 2-3)SPAR, REAR W/DECALS - RIGHT - BLACK (INC. 2-3)
-
13718-137 SPAR, REAR W/DECALS - LEFT - BLACK (INC. 2-3)SPAR, REAR W/DECALS - LEFT - BLACK (INC. 2-3)
-
24706-618 ...SPAR, REAR - RIGHT - BLACK...SPAR, REAR - RIGHT - BLACK
-
24706-613 ...SPAR, REAR - LEFT - BLACK...SPAR, REAR - LEFT - BLACK
-
39611-470 ...DECAL, REAR SPAR - RIGHT...DECAL, REAR SPAR - RIGHT
-
39611-471 ...DECAL, REAR SPAR - LEFT...DECAL, REAR SPAR - LEFT
-
40423-396 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
58053-212 WASHER, EXTERNAL TOOTH LOCKWASHER, EXTERNAL TOOTH LOCK
-
68053-242 WASHER, EXTERNAL TOOTH LOCKWASHER, EXTERNAL TOOTH LOCK
-
78470-510 SCREW, MACHINESCREW, MACHINE
-
80623-727 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
94606-683 CUP, RECOILCUP, RECOIL
-
100423-355 SCREW, SHOULDERSCREW, SHOULDER
-
118427-602 NUT, LOCKNUT, LOCK
-
128060-488 RIVETRIVET
-
134606-329 BRACKET, CROSSOVERBRACKET, CROSSOVER
-
140623-302 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
155606-098 TUBE, SUPPORT - RIGHTTUBE, SUPPORT - RIGHT
-
155706-051 TUBE, SUPPORT - LEFTTUBE, SUPPORT - LEFT
-
168060-484 RIVETRIVET
-
175606-100 BRACKET, ADJUSTABLE - RIGHTBRACKET, ADJUSTABLE - RIGHT
-
175606-101 BRACKET, ADJUSTABLE - LEFTBRACKET, ADJUSTABLE - LEFT
-
188470-520 SCREW, MACHINESCREW, MACHINE
-
195606-094 PLATE, SUPPORT - LOWERPLATE, SUPPORT - LOWER
-
208408-625 SCREW, CAPSCREW, CAP
-
214606-328 PLATE, SUPPORT - UPPERPLATE, SUPPORT - UPPER
-
228408-535 SCREW, CAPSCREW, CAP
-
231623-637 CLIP, U-NUTCLIP, U-NUT
-
240605-948 BRACKET, NUT HOLDERBRACKET, NUT HOLDER
-
258424-602 NUTNUT
