DRIVE CLUTCH для Arctic Cat F5 LXR (GREEN) - 2012 года выпуска

  • №
    Артикул
    Название
  • 1
    0746-443 CLUTCH, DRIVE - UNCALIBRATED (INC. 2-4)
    CLUTCH, DRIVE - UNCALIBRATED (INC. 2-4)
  • 2
    0646-431 ...SCREW, SHOULDER
    ...SCREW, SHOULDER
  • 3
    0646-430 ...WASHER, LOCK
    ...WASHER, LOCK
  • 4
    0646-432 ...SPRING, DRIVE CLUTCH - BLACK/RED
    ...SPRING, DRIVE CLUTCH - BLACK/RED
  • 5
    4639-674 KIT, CAM ARM (WIDE) (INC. 6-9)
    KIT, CAM ARM (WIDE) (INC. 6-9)
  • 6
    8048-366 ...NUT, LOCK
    ...NUT, LOCK
  • 7
    1602-692 ...O-RING
    ...O-RING
  • 8
    1623-183 ...SCREW, SET
    ...SCREW, SET
  • 9
    0646-747 ...PIN, CAM ARM
    ...PIN, CAM ARM
  • 10
    0746-702 ARM, CAM-WIDE (INC. 8)
    ARM, CAM-WIDE (INC. 8)
  • 10
    0746-663 ARM, CAM-WIDE (INC. 8) - 5-9,000 FT ALT.
    ARM, CAM-WIDE (INC. 8) - 5-9,000 FT ALT.
  • 10
    0746-792 ARM, CAM-WIDE (INC. 8) - OVER 9,000 FT ALT.
    ARM, CAM-WIDE (INC. 8) - OVER 9,000 FT ALT.
