PASSENGER SEAT AND BACKREST ASSEMBLY для Arctic Cat TZ1 - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    4706-249 BACKREST - COMPLETE (INC. 2-4)
    BACKREST - COMPLETE (INC. 2-4)
  • 2
    4706-250 ...COVER, BACKREST
    ...COVER, BACKREST
  • 3
    5606-082 ...BACKREST
    ...BACKREST
  • 4
    1623-732 ...CLIP, RETAINING
    ...CLIP, RETAINING
  • 5
    4706-911 SEAT, PASSENGER - ASSEMBLY (INC. 6-41)
    SEAT, PASSENGER - ASSEMBLY (INC. 6-41)
  • 6
    4706-908 ...COVER, PASSENGER SEAT (INC. 7)
    ...COVER, PASSENGER SEAT (INC. 7)
  • 7
    5606-378 ......WIRE, SEAT
    ......WIRE, SEAT
  • 8
    3706-738 ...FOAM, SEAT
    ...FOAM, SEAT
  • 9
    0609-869 ...PAD, SEAT HEATER
    ...PAD, SEAT HEATER
  • 10
    0624-528 ...STAPLE
    ...STAPLE
  • 11
    5606-380 ...WIRE, SEAT
    ...WIRE, SEAT
  • 12
    0623-727 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 13
    5606-178 ...RETAINER, SEAT LATCH
    ...RETAINER, SEAT LATCH
  • 14
    4606-290 ...BASE, SEAT
    ...BASE, SEAT
  • 15
    0406-879 ...BUMPER, SEAT
    ...BUMPER, SEAT
  • 16
    1686-570 ...HARNESS
    ...HARNESS
  • 17
    4706-194 ...ROD, LATCH W/SPRING - RIGHT
    ...ROD, LATCH W/SPRING - RIGHT
  • 17
    4706-195 ...ROD, LATCH W/SPRING - LEFT
    ...ROD, LATCH W/SPRING - LEFT
  • 18
    5606-204 ...ROD, CROSS
    ...ROD, CROSS
  • 19
    4706-090 ...ROD, HANDLE
    ...ROD, HANDLE
  • 20
    3706-808 ...FRAME, SEAT
    ...FRAME, SEAT
  • 21
    5606-095 ...SPRING, ADJUSTMENT
    ...SPRING, ADJUSTMENT
  • 22
    3706-806 ...PLATE, CLAMP - BACKREST
    ...PLATE, CLAMP - BACKREST
  • 23
    4606-291 ...PANEL, SEAT-BASE
    ...PANEL, SEAT-BASE
  • 24
    0423-396 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 25
    1623-774 ...SCREW, CAP
    ...SCREW, CAP
  • 26
    5606-020 ...ROD
    ...ROD
  • 27
    5606-018 ...SPACER
    ...SPACER
  • 28
    0623-853 ...RIVET
    ...RIVET
  • 29
    4706-075 ...SPACER
    ...SPACER
  • 30
    4706-532 ...HANDHOLD - RIGHT
    ...HANDHOLD - RIGHT
  • 30
    5606-085 ...HANDHOLD - LEFT
    ...HANDHOLD - LEFT
  • 31
    8050-217 ...WASHER
    ...WASHER
  • 32
    1623-789 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 33
    0609-835 ...SWITCH, HANDWARMER
    ...SWITCH, HANDWARMER
  • 34
    0609-836 ...SWITCH, SEAT HEATER
    ...SWITCH, SEAT HEATER
  • 35
    1623-703 ...CLIP, SPEED
    ...CLIP, SPEED
  • 36
    0706-371 ...TRIM
    ...TRIM
  • 37
    8476-630 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 38
    8427-602 ...NUT, LOCK
    ...NUT, LOCK
  • 39
    1623-697 ...PLUG
    ...PLUG
  • 40
    5606-212 ...WINDGUARD - RIGHT
    ...WINDGUARD - RIGHT
  • 40
    5606-213 ...WINDGUARD - LEFT
    ...WINDGUARD - LEFT
  • 41
    1623-129 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
