AIR SILENCER ASSEMBLY для Arctic Cat TZ1 TURBO LXR LTD - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    0770-792 INTAKE, SUPPORT - ASSEMBLY (INC. 2-4)
    INTAKE, SUPPORT - ASSEMBLY (INC. 2-4)
  • 2
    1670-732 ...INTAKE, SUPPORT - TOP
    ...INTAKE, SUPPORT - TOP
  • 3
    1670-742 ...INTAKE, SUPPORT - BOTTOM
    ...INTAKE, SUPPORT - BOTTOM
  • 4
    0623-784 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 5
    4606-276 GROMMET
    GROMMET
  • 6
    0423-356 SCREW, SHOULDER
    SCREW, SHOULDER
  • 7
    8050-212 WASHER
    WASHER
  • 8
    4606-275 GROMMET
    GROMMET
  • 9
    8427-602 NUT, LOCK
    NUT, LOCK
  • 10
    1670-764 SEAL, AIR SILENCER
    SEAL, AIR SILENCER
  • 11
    0770-881 SILENCER, AIR - ASSEMBLY (INC. 12-14)
    SILENCER, AIR - ASSEMBLY (INC. 12-14)
  • 12
    1670-952 ...FILTER
    ...FILTER
  • 13
    1670-982 ...COVER
    ...COVER
  • 14
    1623-764 ...NUT, EXPANSION
    ...NUT, EXPANSION
  • 15
    8470-520 SCREW, MACHINE
    SCREW, MACHINE
  • 16
    8408-640 SCREW, CAP
    SCREW, CAP
  • 17
    5606-560 SPACER
    SPACER
  • 18
    1623-762 CLAMP, ROUTING
    CLAMP, ROUTING
  • 19
    8408-635 SCREW,CAP-HFH M6X1.0X35 CL8.8 Z & Y
    SCREW,CAP-HFH M6X1.0X35 CL8.8 Z & Y
  • 20
    1623-796 SCREW,CAP-HFH M6X1.0X35 CL8.8 Z & Y W/203
    SCREW,CAP-HFH M6X1.0X35 CL8.8 Z & Y W/203
  • 21
    0610-751 HOSE, ABV INLET
    HOSE, ABV INLET
  • 22
    1623-291 CLAMP, HOSE
    CLAMP, HOSE
  • 23
    0610-787 HOSE, ABV OUTLET
    HOSE, ABV OUTLET
  • 24
    1623-285 CLAMP, HOSE
    CLAMP, HOSE
  • 25
    1670-950 INTAKE, AIR
    INTAKE, AIR
  • 26
    1623-042 CLAMP, HOSE
    CLAMP, HOSE
  • 27
    6101-001 HOSE, GASLINE - 100 FT
    HOSE, GASLINE - 100 FT
  • 27
    6101-009 HOSE, GASLINE - 50 FT
    HOSE, GASLINE - 50 FT
  • 28
    0670-228 PLUG, DRAIN
    PLUG, DRAIN
  • 29
    1670-951 BOOT, INTAKE
    BOOT, INTAKE
  • 30
    0423-066 CLAMP
    CLAMP
