REAR SUSPENSION REAR ARM ASSEMBLY для Arctic Cat CROSSFIRE R 1000 EFI LE [S2009CFLEXUSB] - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    1704-404 ARM, IDLER - BLACK (INC. 2 AND ONE NO. 3)
    ARM, IDLER - BLACK (INC. 2 AND ONE NO. 3)
  • 2
    1604-100 ...BUSHING, FLARED
    ...BUSHING, FLARED
  • 3
    1623-010 ...FITTING, GREASE
    ...FITTING, GREASE
  • 4
    1704-019 ARM, REAR - BLACK (INC. ONE NO. 3 AND 5)
    ARM, REAR - BLACK (INC. ONE NO. 3 AND 5)
  • 5
    1623-011 ...WASHER
    ...WASHER
  • 6
    1623-037 SCREW, CAP
    SCREW, CAP
  • 7
    0623-439 WASHER
    WASHER
  • 8
    2604-664 BUSHING, REAR ARM
    BUSHING, REAR ARM
  • 9
    2604-663 AXLE, INNER
    AXLE, INNER
  • 10
    8047-490 NUT, LOCK
    NUT, LOCK
  • 11
    1623-086 SCREW, CAP
    SCREW, CAP
  • 12
    8047-486 NUT, LOCK
    NUT, LOCK
  • 13
    2604-370 AXLE
    AXLE
  • 14
    1604-204 BLOCK, SPRING ADJUSTER - RIGHT
    BLOCK, SPRING ADJUSTER - RIGHT
  • 14
    1604-205 BLOCK, SPRING ADJUSTER - LEFT
    BLOCK, SPRING ADJUSTER - LEFT
  • 15
    0623-138 RING, RETAINING
    RING, RETAINING
  • 16
    3604-024 SLEEVE, SPRING
    SLEEVE, SPRING
  • 17
    1704-576 SPRING, SUSPENSION - RIGHT
    SPRING, SUSPENSION - RIGHT
  • 17
    1704-577 SPRING, SUSPENSION - LEFT
    SPRING, SUSPENSION - LEFT
  • 18
    0604-051 WHEEL, IDLER (INC. 19-20)
    WHEEL, IDLER (INC. 19-20)
  • 19
    0107-598 ...BEARING
    ...BEARING
  • 20
    0123-798 ...RING, RETAINING
    ...RING, RETAINING
  • 21
    2604-980 SPACER, PIVOT - IDLER ARM
    SPACER, PIVOT - IDLER ARM
  • 22
    3604-158 AXLE, POWDER METAL
    AXLE, POWDER METAL
  • 23
    1604-187 WASHER, PIVOT - IDLER ARM
    WASHER, PIVOT - IDLER ARM
  • 24
    1704-522 ARM, PIVOT IDLER (INC. 25-27)
    ARM, PIVOT IDLER (INC. 25-27)
  • 25
    3604-028 ...BUSHING, FLARED
    ...BUSHING, FLARED
  • 26
    8020-138 ...SCREW, CAP
    ...SCREW, CAP
  • 27
    8047-426 ...NUT, LOCK
    ...NUT, LOCK
  • 28
    1623-166 SCREW, CAP
    SCREW, CAP
  • 29
    8020-233 SCREW, CAP
    SCREW, CAP
  • 30
    1604-498 AXLE, LINK - FLANGED
    AXLE, LINK - FLANGED
  • 31
    1704-416 LINK, REAR SHOCK - BLACK
    LINK, REAR SHOCK - BLACK
  • 32
    0604-298 SPACER, SHOCK LINK - BLACK
    SPACER, SHOCK LINK - BLACK
  • 33
    8041-486 NUT, LOCK
    NUT, LOCK
  • 34
    1604-139 SLEEVE, SHOCK
    SLEEVE, SHOCK
  • 35
    8020-226 SCREW, CAP
    SCREW, CAP
  • 36
    1704-807 SHOCK ABSORBER
    SHOCK ABSORBER
  • 37
    0623-044 WASHER
    WASHER
