STEERING POST ASSEMBLY для Arctic Cat CROSSFIRE R 1000 EFI GREEN [S2009CFLRUSB] - 2009 года выпуска
-
№АртикулНазвание
-
11705-191 LEVER, CAM - ASSEMBLY (INC. 2)LEVER, CAM - ASSEMBLY (INC. 2)
-
20605-839 ...KNOB, LOCKING PIN...KNOB, LOCKING PIN
-
30605-837 WASHER, CAM LEVERWASHER, CAM LEVER
-
40605-828 CUP, CAM LEVERCUP, CAM LEVER
-
51705-268 BLOCK, RISER - ASSEMBLYBLOCK, RISER - ASSEMBLY
-
60605-832 RETAINER, RISER BLOCK - RIGHTRETAINER, RISER BLOCK - RIGHT
-
70605-833 RETAINER, RISER BLOCK - LEFTRETAINER, RISER BLOCK - LEFT
-
81623-018 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
90605-831 END, LOCK RODEND, LOCK ROD
-
100605-840 SPRING, RISER BLOCKSPRING, RISER BLOCK
-
111705-287 POST, STEERINGPOST, STEERING
-
120605-576 BLOCK, MOUNTING - STEERING POSTBLOCK, MOUNTING - STEERING POST
-
130605-943 STOP, STEERING POSTSTOP, STEERING POST
-
148060-888 RIVETRIVET
-
150623-044 WASHERWASHER
-
160623-025 NUT, LOCKNUT, LOCK
-
178004-225 SCREW, CAPSCREW, CAP
-
180605-504 BALL JOINT, TIE ROD - RIGHT-HAND THREADBALL JOINT, TIE ROD - RIGHT-HAND THREAD
-
190623-294 NUT, HEX - RIGHT-HAND THREADNUT, HEX - RIGHT-HAND THREAD
-
200605-856 TUBE, TIE RODTUBE, TIE ROD
-
210123-917 NUT, HEX - LEFT-HAND THREADNUT, HEX - LEFT-HAND THREAD
-
220605-511 BALL JOINT, TIE ROD - LEFT-HAND THREADBALL JOINT, TIE ROD - LEFT-HAND THREAD
-
230706-371 TRIMTRIM
-
245606-501 PANEL, CLOSE-OUTPANEL, CLOSE-OUT
-
251623-353 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
261705-260 SUPPORT, STEERINGSUPPORT, STEERING
-
278047-426 NUT, LOCKNUT, LOCK
-
288050-252 WASHERWASHER
-
290623-677 TIE, CABLE - PUSH-MOUNTTIE, CABLE - PUSH-MOUNT
-
301623-406 CLIP, RETAININGCLIP, RETAINING
-
311623-482 SCREW, CAPSCREW, CAP
