DRIVE CLUTCH для Arctic Cat CROSSFIRE R 1000 EFI GREEN [S2009CFLRUSB] - 2009 года выпуска

  • №
    Артикул
    Название
  • -
    0746-212 UNCALIBRATED DRIVE CLUTCH
    UNCALIBRATED DRIVE CLUTCH
  • 1
    1623-670 SCREW, CAP
    SCREW, CAP
  • 2
    8051-242 WASHER, LOCK
    WASHER, LOCK
  • 3
    0646-155 SPRING, DRIVE CLUTCH - PURPLE
    SPRING, DRIVE CLUTCH - PURPLE
  • 3
    0646-229 SPRING, DRIVE CLUTCH - YELLOW/WHITE (OVER 3,000 FT ALT.)
    SPRING, DRIVE CLUTCH - YELLOW/WHITE (OVER 3,000 FT ALT.)
  • 4
    0746-773 ARM, CAM (INC. 5)
    ARM, CAM (INC. 5)
  • 4
    0746-814 ARM, CAM (INC. 5) (3-6,000 FT ALT.)
    ARM, CAM (INC. 5) (3-6,000 FT ALT.)
  • 4
    0746-673 ARM, CAM (INC. 5) (6-9,000 FT ALT.)
    ARM, CAM (INC. 5) (6-9,000 FT ALT.)
  • 4
    0746-672 ARM, CAM (INC. 5) (OVER 9,000 FT ALT.)
    ARM, CAM (INC. 5) (OVER 9,000 FT ALT.)
  • 5
    1623-183 ...SCREW, SET
    ...SCREW, SET
  • 6
    1602-692 O-RING
    O-RING
  • 7
    0646-747 PIN, CAM ARM
    PIN, CAM ARM
  • 8
    8048-366 NUT, LOCK
    NUT, LOCK
