HOOD AND WINDSHIELD ASSEMBLY для Arctic Cat AC M6 - 2009 года выпуска`
-
№АртикулНазвание
-
12718-496 HOOD W/DECALS - BLACK (INC. 2-10)HOOD W/DECALS - BLACK (INC. 2-10)
-
22718-146 ...HOOD W/O DECALS - BLACK (INC. 3-6)...HOOD W/O DECALS - BLACK (INC. 3-6)
-
31623-026 ......PIN, CLEVIS......PIN, CLEVIS
-
40623-847 ......CLIP, HAIRPIN......CLIP, HAIRPIN
-
56611-143 ......DECAL, CAUTION......DECAL, CAUTION
-
66611-144 ......DECAL, WARNING - ENGLISH......DECAL, WARNING - ENGLISH
-
66611-145 ......DECAL, WARNING - FRENCH......DECAL, WARNING - FRENCH
-
78611-322 ...DECAL, HOOD - LOWER RIGHT...DECAL, HOOD - LOWER RIGHT
-
78611-323 ...DECAL, HOOD - LOWER LEFT...DECAL, HOOD - LOWER LEFT
-
88611-324 ...DECAL, HOOD - UPPER RIGHT...DECAL, HOOD - UPPER RIGHT
-
88611-325 ...DECAL, HOOD - UPPER LEFT...DECAL, HOOD - UPPER LEFT
-
98611-326 ...DECAL, HOOD - CREST...DECAL, HOOD - CREST
-
108611-267 ...DECAL, AIRCAT - CHROME...DECAL, AIRCAT - CHROME
-
112706-793 SCREEN, VENT - CENTERSCREEN, VENT - CENTER
-
123706-260 SCREEN, VENT - FRONT - RIGHTSCREEN, VENT - FRONT - RIGHT
-
123706-261 SCREEN, VENT - FRONT - LEFTSCREEN, VENT - FRONT - LEFT
-
132706-796 SCREEN, VENT - REAR - RIGHTSCREEN, VENT - REAR - RIGHT
-
132706-797 SCREEN, VENT - REAR - LEFTSCREEN, VENT - REAR - LEFT
-
141623-694 CLIP, RETAININGCLIP, RETAINING
-
150617-510 FOAM, HOOD - RIGHTFOAM, HOOD - RIGHT
-
150617-545 FOAM, HOOD - LEFTFOAM, HOOD - LEFT
-
160617-489 FOAM, HOOD - REARFOAM, HOOD - REAR
-
173606-868 WINDSHIELDWINDSHIELD
-
180616-032 O-RINGO-RING
-
190623-362 RIVET, REINSTALLABLERIVET, REINSTALLABLE
-
200617-486 FOAM, INTAKE BEZEL - RIGHTFOAM, INTAKE BEZEL - RIGHT
-
200617-487 FOAM, INTAKE BEZEL - LEFTFOAM, INTAKE BEZEL - LEFT
-
215606-080 BEZEL, INTAKE - RIGHTBEZEL, INTAKE - RIGHT
-
215606-081 BEZEL, INTAKE - LEFTBEZEL, INTAKE - LEFT
-
220623-302 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
232606-726 CABLE, HOODCABLE, HOOD
-
241623-052 CLIP, U-NUTCLIP, U-NUT
Все узлы модели:
- A-ARM ASSEMBLY
- AIR INTAKE ASSEMBLY
- AIR SILENCER ASSEMBLY
- BELLY PAN AND FRONT BUMPER ASSEMBLY
- BELT GUARD ASSEMBLY
- CONSOLE AND SWITCH ASSEMBLY
- COOLING ASSEMBLY
- CRANKCASE ASSEMBLY
- CYLINDER AND HEAD ASSEMBLY
- DRIVE CLUTCH
- DRIVE TRAIN SHAFT AND BRAKE ASSEMBLIES
- DRIVEN CLUTCH
- ELECTRICAL
- ENGINE AND RELATED PARTS
- EXHAUST ASSEMBLY
- FRONT FRAME AND FOOTREST ASSEMBLY
- FRONT SUSPENSION SHOCK ABSORBER
- FRONT SUSPENSION SHOCK ABSORBER ASSEMBLY
- FUEL PUMP ASSEMBLY
- GAS TANK ASSEMBLY
- GEARCASE ASSEMBLY
- HANDLEBAR AND CONTROLS
- HEADLIGHT- INSTRUMENTS- AND WIRING ASSEMBLIES
- • HOOD AND WINDSHIELD ASSEMBLY
- HYDRAULIC BRAKE ASSEMBLY
- IDLER WHEEL ASSEMBLY
- MAGNETO
- OIL PUMP
- OIL TANK ASSEMBLY
- PISTON AND CRANKSHAFT
- REAR SUSPENSION FRONT ARM ASSEMBLY
- REAR SUSPENSION FRONT ARM SHOCK ABSORBER
- REAR SUSPENSION REAR ARM ASSEMBLY
- REAR SUSPENSION REAR ARM SHOCK ABSORBER
- RECOIL STARTER
- REED VALVE ASSEMBLY
- SEAT ASSEMBLY
- SERVOMOTOR ASSEMBLY
- SKI AND SPINDLE ASSEMBLY
- SLIDE RAIL AND TRACK ASSEMBLY
- STEERING POST ASSEMBLY
- THROTTLE BODY ASSEMBLY
- TIE ROD ASSEMBLY
- TUNNEL- REAR BUMPER- AND TAILLIGHT ASSEMBLY
- WATER PUMP AND THERMOSTAT
