REAR SUSPENSION FRONT ARM SHOCK ABSORBER для Arctic Cat 600 SNO PRO INTERNATIONAL - 2009 года выпуска

  • №
    Артикул
    Название
  • -
    1704-838 COMPLETE SHOCK ABSORBER
    COMPLETE SHOCK ABSORBER
  • 1
    0603-910 EYELET, SHOCK
    EYELET, SHOCK
  • 2
    3604-525 ROD, SHOCK
    ROD, SHOCK
  • 3
    3604-538 KIT, SEAL/REBUILD (INC. 4-8)
    KIT, SEAL/REBUILD (INC. 4-8)
  • 4
    3604-530 ...BUMPER
    ...BUMPER
  • 5
    2604-812 ...BEARING - ASSEMBLY
    ...BEARING - ASSEMBLY
  • 6
    0603-292 ...STRAP, PISTON
    ...STRAP, PISTON
  • 7
    2604-214 ...O-RING
    ...O-RING
  • 8
    0603-301 ...NUT
    ...NUT
  • 9
    2603-474 SPACER
    SPACER
  • 10
    0603-540 WASHER, TOP OUT
    WASHER, TOP OUT
  • 11
    0603-347 VALVE, SHOCK 1.250 X 0.010 IN.
    VALVE, SHOCK 1.250 X 0.010 IN.
  • 12
    0603-334 VALVE, SHOCK 0.800 X 0.008 IN.
    VALVE, SHOCK 0.800 X 0.008 IN.
  • 13
    0603-337 VALVE, SHOCK 0.900 X 0.010 IN.
    VALVE, SHOCK 0.900 X 0.010 IN.
  • 14
    0603-349 VALVE, SHOCK 1.300 X 0.008 IN.
    VALVE, SHOCK 1.300 X 0.008 IN.
  • 15
    2604-965 PISTON, 0.041 IN. - ORIFICE
    PISTON, 0.041 IN. - ORIFICE
  • 16
    0603-342 VALVE, SHOCK 1.100 X 0.006 IN.
    VALVE, SHOCK 1.100 X 0.006 IN.
  • 17
    3604-533 VALVE, SHOCK 0.600 X 0.012 IN.
    VALVE, SHOCK 0.600 X 0.012 IN.
  • 18
    0603-335 VALVE, SHOCK 0.800 X 0.010 IN.
    VALVE, SHOCK 0.800 X 0.010 IN.
  • 19
    3604-170 WASHER, TOP OUT
    WASHER, TOP OUT
  • 20
    0603-389 WASHER, BACKUP
    WASHER, BACKUP
  • 21
    2603-246 SLEEVE, WEAR
    SLEEVE, WEAR
  • 22
    2603-245 RETAINER, SLEEVE
    RETAINER, SLEEVE
  • 23
    3604-523 BODY, SHOCK
    BODY, SHOCK
  • 24
    2604-840 NUT, ADJUSTER
    NUT, ADJUSTER
  • 25
    2604-841 COLLAR, LOCKING - ADJUSTER NUT
    COLLAR, LOCKING - ADJUSTER NUT
  • 26
    3604-522 END CAP, SHOCK/RESERVOIR (INC. 27-29)
    END CAP, SHOCK/RESERVOIR (INC. 27-29)
  • 27
    3604-532 ...CLAMP, BODY/END CAP
    ...CLAMP, BODY/END CAP
  • 28
    3604-526 ...BEARING
    ...BEARING
  • 29
    3604-527 ...RING, RETAINING
    ...RING, RETAINING
  • 30
    3604-539 REBUILD KIT, RESERVOIR (INC. 31-35)
    REBUILD KIT, RESERVOIR (INC. 31-35)
  • 31
    1603-235 ...STRAP, PISTON
    ...STRAP, PISTON
  • 32
    1604-316 ...SCREW, RELIEF (INC. 33)
    ...SCREW, RELIEF (INC. 33)
  • 33
    1604-425 ......O-RING
    ......O-RING
  • 34
    2603-502 ...O-RING
    ...O-RING
  • 35
    0603-671 ...O-RING
    ...O-RING
  • 36
    3604-528 RESERVOIR
    RESERVOIR
  • 37
    3604-160 DECAL, SHOCK - RESERVOIR
    DECAL, SHOCK - RESERVOIR
  • 38
    3604-524 PISTON, INTERNAL FLOATING
    PISTON, INTERNAL FLOATING
  • 39
    0604-992 RING, RETAINING
    RING, RETAINING
  • 40
    3604-517 END CAP, RESERVOIR (INC. 35 AND 41-43)
    END CAP, RESERVOIR (INC. 35 AND 41-43)
  • 41
    1604-428 ...PLUG
    ...PLUG
  • 42
    2603-338 ...SCREW, SET (FAV3 VALVE)
    ...SCREW, SET (FAV3 VALVE)
  • 43
    2603-337 ...BALL
    ...BALL
  • 44
    3604-187 PISTON, CONCENTRIC - DAMPING ADJUSTER (INC. 45-47)
    PISTON, CONCENTRIC - DAMPING ADJUSTER (INC. 45-47)
  • 45
    0603-331 ...VALVE, SHOCK 0.700 X 0.008 IN.
    ...VALVE, SHOCK 0.700 X 0.008 IN.
  • 46
    2603-501 ...VALVE, SHOCK 0.700 X 0.010 IN.
    ...VALVE, SHOCK 0.700 X 0.010 IN.
  • 47
    3604-165 ...PLATE, BACKUP
    ...PLATE, BACKUP
  • 48
    2603-527 CARTRIDGE, DAMPING ADJUSTER (INC. 34)
    CARTRIDGE, DAMPING ADJUSTER (INC. 34)
  • 49
    5639-240 OIL, SHOCK - 1 QT
    OIL, SHOCK - 1 QT
