GAS TANK ASSEMBLY для Arctic Cat JAGUAR Z1 NIGHTFIRE SNO PRO - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    0770-820 TANK, GAS (INC. 2-7)
    TANK, GAS (INC. 2-7)
  • 2
    1670-890 ...CAP, GAS TANK - ASSEMBLY (INC. 3-4)
    ...CAP, GAS TANK - ASSEMBLY (INC. 3-4)
  • 3
    1670-816 ......SEAL, GAS TANK CAP
    ......SEAL, GAS TANK CAP
  • 4
    7611-810 ......DECAL, GAS TANK CAP
    ......DECAL, GAS TANK CAP
  • 5
    8479-365 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 6
    1670-325 ...GROMMET
    ...GROMMET
  • 7
    1670-494 ...FITTING, ELBOW
    ...FITTING, ELBOW
  • 8
    1623-233 CLAMP, HOSE
    CLAMP, HOSE
  • 9
    6101-001 HOSE, GASLINE - 100 FT
    HOSE, GASLINE - 100 FT
  • 9
    6101-009 HOSE, GASLINE - 50 FT
    HOSE, GASLINE - 50 FT
  • 10
    0610-059 VALVE, CHECK
    VALVE, CHECK
  • 11
    0670-921 Y-FITTING
    Y-FITTING
  • 12
    1670-913 VALVE, PRESSURE-RELIEF
    VALVE, PRESSURE-RELIEF
  • 13
    0423-577 CLIP, U-NUT
    CLIP, U-NUT
  • 14
    3706-408 KNEE PANEL - RIGHT
    KNEE PANEL - RIGHT
  • 14
    3706-409 KNEE PANEL - LEFT
    KNEE PANEL - LEFT
  • 15
    8470-510 SCREW, MACHINE
    SCREW, MACHINE
  • 16
    0423-101 SCREW, BODY
    SCREW, BODY
  • 17
    0619-946 TAPE, FOAM - 1 FT
    TAPE, FOAM - 1 FT
  • 18
    0123-903 CABLE TIE - 11.5 IN.
    CABLE TIE - 11.5 IN.
