STEERING POST AND TIE ROD ASSEMBLY для Arctic Cat AC 120 (PINK) - 2008 года выпуска`
-
№АртикулНазвание
-
11703-866 POST, STEERING - BLACKPOST, STEERING - BLACK
-
21606-765 GRIP, HANDLEGRIP, HANDLE
-
30302-165 CONTROL, THROTTLECONTROL, THROTTLE
-
40109-609 LEVER, THROTTLE/BRAKELEVER, THROTTLE/BRAKE
-
58070-318 PIN, SPRINGPIN, SPRING
-
60611-022 DECAL, ENGINE STOP SWITCHDECAL, ENGINE STOP SWITCH
-
70123-230 PINPIN
-
80123-231 RING, RETAININGRING, RETAINING
-
90302-147 HOUSING, BRAKEHOUSING, BRAKE
-
100609-007 SWITCH, ENGINE STOPSWITCH, ENGINE STOP
-
110605-887 COVER, HANDLEBAR PADCOVER, HANDLEBAR PAD
-
120605-501 PAD, HANDLEBARPAD, HANDLEBAR
-
130687-200 CABLE, THROTTLECABLE, THROTTLE
-
148053-212 WASHER, LOCK - EXTERNAL TOOTHWASHER, LOCK - EXTERNAL TOOTH
-
150123-788 CABLE TIE - 7 IN.CABLE TIE - 7 IN.
-
160687-122 CABLE, BRAKECABLE, BRAKE
-
171602-100 SPRING, RETURN - BRAKESPRING, RETURN - BRAKE
-
180605-444 BEARING, STEERING POSTBEARING, STEERING POST
-
190705-896 RETAINER, BEARINGRETAINER, BEARING
-
208020-040 SCREW, CAPSCREW, CAP
-
212706-144 SUPPORT, STEERING POSTSUPPORT, STEERING POST
-
220630-138 SWITCH, TETHER - ASSEMBLY (INC. 23)SWITCH, TETHER - ASSEMBLY (INC. 23)
-
230630-139 ...CORD, TETHER SWITCH...CORD, TETHER SWITCH
-
248047-366 NUT, LOCKNUT, LOCK
-
258060-504 RIVET, BLINDRIVET, BLIND
-
268004-135 SCREW, CAPSCREW, CAP
-
278050-247 WASHERWASHER
-
281623-423 NUT, LOCKNUT, LOCK
-
291703-853 TIE ROD - ASSEMBLY (INC. 30-33)TIE ROD - ASSEMBLY (INC. 30-33)
-
300623-260 ...NUT, HEX - LEFT-HAND THREAD...NUT, HEX - LEFT-HAND THREAD
-
310605-777 ...ROD END - LEFT-HAND THREAD...ROD END - LEFT-HAND THREAD
-
320123-144 ...NUT, HEX - RIGHT-HAND THREAD...NUT, HEX - RIGHT-HAND THREAD
-
330605-776 ...ROD END - RIGHT-HAND THREAD...ROD END - RIGHT-HAND THREAD
