HANDLEBAR AND CONTROLS для Arctic Cat Z 370 (ORANGE) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    0609-387 CONTROL, THROTTLE (INC. 2-6, ONE NO. 7, 8, EIGHT NO. 9, 10, AND ONE NO. 11)
    CONTROL, THROTTLE (INC. 2-6, ONE NO. 7, 8, EIGHT NO. 9, 10, AND ONE NO. 11)
  • 2
    0609-283 ...DECAL, MARK PLATE
    ...DECAL, MARK PLATE
  • 3
    0623-215 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 4
    0609-282 ...KNOB, EMERGENCY STOP
    ...KNOB, EMERGENCY STOP
  • 5
    0609-319 ...CLAMP, HARNESS - SINGLE
    ...CLAMP, HARNESS - SINGLE
  • 6
    0609-321 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 7
    0609-085 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 8
    0609-316 ...COVER, THROTTLE SWITCH
    ...COVER, THROTTLE SWITCH
  • 9
    0609-312 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 10
    0609-384 ...CONTROL, THUMBWARMER (INC. ONE NO. 11 AND THREE NO. 9)
    ...CONTROL, THUMBWARMER (INC. ONE NO. 11 AND THREE NO. 9)
  • 11
    0609-378 ......PLATE, COVER
    ......PLATE, COVER
  • 12
    0609-257 LEVER, THROTTLE
    LEVER, THROTTLE
  • 13
    0609-317 AXLE, LEVER - THROTTLE
    AXLE, LEVER - THROTTLE
  • 14
    0609-038 SEAL, THROTTLE LEVER
    SEAL, THROTTLE LEVER
  • 15
    0609-036 WASHER
    WASHER
  • 16
    0609-040 RING, RETAINING
    RING, RETAINING
  • 17
    2606-084 GRIP, HANDLEBAR
    GRIP, HANDLEBAR
  • 18
    0705-360 HANDLEBAR
    HANDLEBAR
  • 19
    0605-354 PAD, HANDLEBAR - FRONT
    PAD, HANDLEBAR - FRONT
  • 20
    0605-353 PAD, HANDLEBAR - REAR
    PAD, HANDLEBAR - REAR
  • 21
    0605-683 WRAP, HANDLEBAR PAD
    WRAP, HANDLEBAR PAD
  • 22
    0617-248 PAD, INSULATOR
    PAD, INSULATOR
  • 23
    0609-685 ELEMENT, THUMBWARMER
    ELEMENT, THUMBWARMER
  • 24
    0123-231 RING, RETAINING
    RING, RETAINING
  • 25
    0687-084 CABLE, THROTTLE (INC. 26)
    CABLE, THROTTLE (INC. 26)
  • 26
    0623-464 ...NUT, LOCKING - THROTTLE CABLE
    ...NUT, LOCKING - THROTTLE CABLE
  • 27
    0124-057 E-RING
    E-RING
  • 28
    0124-056 WASHER
    WASHER
  • 29
    0123-788 CABLE TIE - 8 IN.
    CABLE TIE - 8 IN.
  • 30
    0623-262 CLIP, WIRE
    CLIP, WIRE
  • 31
    0609-684 ELEMENT, HANDWARMER
    ELEMENT, HANDWARMER
  • 32
    0609-393 SWITCH, BRAKE - ASSEMBLY (INC. ONE NO. 7, SEVEN NO. 9, ONE NO. 11, AND 33-40)
    SWITCH, BRAKE - ASSEMBLY (INC. ONE NO. 7, SEVEN NO. 9, ONE NO. 11, AND 33-40)
  • 33
    0609-478 ...HOUSING, BRAKE SWITCH (ON/OFF)
    ...HOUSING, BRAKE SWITCH (ON/OFF)
  • 34
    0609-452 ...SWITCH, DIMMER - BRAKE
    ...SWITCH, DIMMER - BRAKE
  • 35
    0609-050 ...PIN, ACTUATOR
    ...PIN, ACTUATOR
  • 36
    0609-314 ...ACTUATOR, BRAKE - PARKING
    ...ACTUATOR, BRAKE - PARKING
  • 37
    0609-051 ...RING, RETAINING
    ...RING, RETAINING
  • 38
    0609-313 ...SPRING, ACTUATOR
    ...SPRING, ACTUATOR
  • 39
    0609-385 ...CONTROL, HANDWARMER (INC. THREE NO. 9 AND ONE NO. 11)
    ...CONTROL, HANDWARMER (INC. THREE NO. 9 AND ONE NO. 11)
  • 40
    0609-474 ...KNOB, DIMMER SWITCH
    ...KNOB, DIMMER SWITCH
  • 41
    0609-315 AXLE, LEVER - BRAKE
    AXLE, LEVER - BRAKE
  • 42
    0609-266 LEVER, BRAKE
    LEVER, BRAKE
  • 43
    0687-089 CABLE, BRAKE
    CABLE, BRAKE
  • 44
    0109-194 SPRING, BRAKE CABLE
    SPRING, BRAKE CABLE
  • 45
    0123-406 NUT, FLANGE
    NUT, FLANGE
