HEADLIGHT- INSTRUMENTS- AND WIRING ASSEMBLIES для Arctic Cat T660 TURBO TOURING (GREEN LE) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    1686-229 HARNESS, MAIN
    HARNESS, MAIN
  • 2
    1686-244 HARNESS, HOOD
    HARNESS, HOOD
  • 3
    0123-788 CABLE TIE - 8 IN.
    CABLE TIE - 8 IN.
  • 4
    0609-530 LENS/REFLECTOR - HEADLIGHT - RIGHT (INC. 5)
    LENS/REFLECTOR - HEADLIGHT - RIGHT (INC. 5)
  • 4
    0609-531 LENS/REFLECTOR - HEADLIGHT - LEFT (INC. 5)
    LENS/REFLECTOR - HEADLIGHT - LEFT (INC. 5)
  • 5
    0609-251 ...BULB, HEADLIGHT
    ...BULB, HEADLIGHT
  • 6
    0623-360 SPRING, ADJUSTER
    SPRING, ADJUSTER
  • 7
    1623-025 INSERT
    INSERT
  • 8
    1623-189 CLIP, ADJUSTER SCREW
    CLIP, ADJUSTER SCREW
  • 9
    1623-024 SCREW, ADJUSTER
    SCREW, ADJUSTER
  • 10
    0620-292 TACHOMETER/SPEEDOMETER (INC. 11-12)
    TACHOMETER/SPEEDOMETER (INC. 11-12)
  • 11
    0620-281 ...BRACKET, RETAINING
    ...BRACKET, RETAINING
  • 12
    0620-280 ...NUT W/WASHER
    ...NUT W/WASHER
  • 13
    3606-370 FOIL, HEADLIGHT - RIGHT
    FOIL, HEADLIGHT - RIGHT
  • 13
    3606-371 FOIL, HEADLIGHT - LEFT
    FOIL, HEADLIGHT - LEFT
  • 14
    1623-202 CLIP, HEADLIGHT - RIGHT
    CLIP, HEADLIGHT - RIGHT
  • 14
    1623-201 CLIP, HEADLIGHT - LEFT
    CLIP, HEADLIGHT - LEFT
  • 15
    1623-137 CLIP, HAIRPIN
    CLIP, HAIRPIN
  • 16
    0630-189 ANTENNA, CONTROL MODULE
    ANTENNA, CONTROL MODULE
  • 17
    0630-187 CONTROL, REMOTE
    CONTROL, REMOTE
  • 18
    0630-213 MODULE, CONTROL - REMOTE START
    MODULE, CONTROL - REMOTE START
  • 19
    8017-397 SCREW, MACHINE
    SCREW, MACHINE
  • 20
    3002-964 CLAMP, WIRE
    CLAMP, WIRE
  • 21
    0123-802 WASHER
    WASHER
  • 22
    8041-246 NUT, LOCK
    NUT, LOCK
  • 23
    0630-013 BOOT, SWITCH
    BOOT, SWITCH
  • 24
    0630-011 SWITCH, HOOD
    SWITCH, HOOD
