GAS TANK- SEAT- AND TAILLIGHT ASSEMBLY для Arctic Cat ZR 120 - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    1718-331 COMPLETE SEAT ASSEMBLY (INC. 2, 8 AND 20)
    COMPLETE SEAT ASSEMBLY (INC. 2, 8 AND 20)
  • 2
    2606-844 TANK, GAS/SEAT, BASE
    TANK, GAS/SEAT, BASE
  • 3
    1706-143 COVER, SEAT
    COVER, SEAT
  • 4
    1706-017 FOAM, SEAT
    FOAM, SEAT
  • 5
    1670-084 CAP, GAS TANK (INC. 6)
    CAP, GAS TANK (INC. 6)
  • 6
    0109-733 SEAL, TANK CAP
    SEAL, TANK CAP
  • 7
    2606-942 WIRE, SEAT
    WIRE, SEAT
  • 8
    2606-031 WIRE, SEAT
    WIRE, SEAT
  • 9
    0676-017 VALVE, SHUT, OFF, GAS TANK
    VALVE, SHUT, OFF, GAS TANK
  • 10
    6101-001 HOSE, GASLINE/VENT (100 FT)
    HOSE, GASLINE/VENT (100 FT)
  • 10
    6101-009 HOSE, GASLINE/VENT (50 FT)
    HOSE, GASLINE/VENT (50 FT)
  • 11
    0510-335 FILTER, FUEL
    FILTER, FUEL
  • 12
    0670-289 TAPE, TEFLON
    TAPE, TEFLON
  • 13
    0609-070 TAILLIGHT ASSEMBLY (INC. 14)
    TAILLIGHT ASSEMBLY (INC. 14)
  • 14
    0230-020 BULB, TAILLIGHT
    BULB, TAILLIGHT
  • 15
    8050-157 WASHER
    WASHER
  • 16
    0123-709 NUT W/LOCK WASHER
    NUT W/LOCK WASHER
  • 17
    0623-184 WASHER
    WASHER
  • 18
    0123-108 NUT, NYLON CAP
    NUT, NYLON CAP
  • 19
    0687-154 CABLE, CHOKE (INC. 21)
    CABLE, CHOKE (INC. 21)
  • 20
    0624-528 STAPLE, SEAT COVER
    STAPLE, SEAT COVER
  • 21
    0687-181 NUT, CHOKE CABLE
    NUT, CHOKE CABLE
  • 22
    4611-767 DECAL, SWITCH/CHOKE
    DECAL, SWITCH/CHOKE
  • 23
    0609-111 NUT, RETAINING
    NUT, RETAINING
  • 24
    0109-822 SWITCH, IGNITION (INC. 23 AND 25)
    SWITCH, IGNITION (INC. 23 AND 25)
  • 25
    0116-065 KEY
    KEY
  • 26
    8041-366 NUT, LOCK
    NUT, LOCK
  • 27
    8002-040 SCREW, CAP
    SCREW, CAP
  • 28
    3611-856 DECAL, SHUT, OFF VALVE
    DECAL, SHUT, OFF VALVE
  • 29
    0123-579 NUT, PUSH
    NUT, PUSH
  • 30
    0123-788 CABLE TIE, 7 IN.
    CABLE TIE, 7 IN.
  • 31
    0123-394 CLIP, CABLE
    CLIP, CABLE
  • 32
    0116-469 BUSHING, RECOIL STARTER
    BUSHING, RECOIL STARTER
