CARBURETOR AND FUEL PUMP ASSEMBLY для Arctic Cat MOUNTAIN CAT 570 - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    0770-623 CARBURETOR ASSY, VM34, 589
    CARBURETOR ASSY, VM34, 589
  • 2
    0623-652 CLAMP, HOSE
    CLAMP, HOSE
  • 3
    0610-442 HOSE, DRAIN
    HOSE, DRAIN
  • 4
    0115-544 FLANGE, CARBURETOR (INC. 5)
    FLANGE, CARBURETOR (INC. 5)
  • 5
    0109-709 CLAMP, CARBURETOR FLANGE
    CLAMP, CARBURETOR FLANGE
  • 6
    0670-210 SPACER
    SPACER
  • 7
    1670-310 BOOT, AIR SILENCER (RIGHT)
    BOOT, AIR SILENCER (RIGHT)
  • 7
    1670-263 BOOT, AIR SILENCER (LEFT)
    BOOT, AIR SILENCER (LEFT)
  • 7
    0610-008 HOSE, GASLINE (25 FT)
    HOSE, GASLINE (25 FT)
  • 8
    0610-015 HOSE, GASLINE (100 FT)
    HOSE, GASLINE (100 FT)
  • 8
    0610-016 HOSE, GASLINE (25 FT)
    HOSE, GASLINE (25 FT)
  • 9
    0124-045 CLAMP, HOSE
    CLAMP, HOSE
  • 10
    1670-166 FILTER, FUEL
    FILTER, FUEL
  • 11
    0610-007 HOSE, IMPULSE (25 FT)
    HOSE, IMPULSE (25 FT)
  • 12
    0610-017 HOSE, GASLINE (100 FT)
    HOSE, GASLINE (100 FT)
  • 13
    0623-502 CLAMP, HOSE
    CLAMP, HOSE
  • 14
    1670-262 PUMP, FUEL
    PUMP, FUEL
  • 15
    0623-877 NUT W/WASHER
    NUT W/WASHER
  • 16
    0716-558 CONDUIT, FLEXIBLE (10 FT)
    CONDUIT, FLEXIBLE (10 FT)
  • 17
    0123-811 CABLE TIE, 4 IN.
    CABLE TIE, 4 IN.
